The following table shows the key characteristics of the various NCU versions:
Table 2-1 Versions of the NCU 1760
DRIVE-CLiQ ports 6
Axes 31 CNC axes (max. 50 axes, incl. PLC axes)
NX10.3 / 15.3 Up to 5
TCU Up to 4
Channels 10
Mode groups (BAG) 10
Maximum resolution with SINUMERIK Operate for
NCU
1920 x 1080px
2.4 Ordering data
Table 2-2 Order data for system components
System component Article number
NCU 1760 6FC5317-6AA00-0AA0
Numeric Control Extension NX15.3 (High Extension) 6SL3040-1NB00-0AA0
Numeric Control Extension NX10.3 (Standard Extension) 6SL3040-1NC00-0AA0
PP 72/48D PN I/O module 6FC5311-0AA00-0AA0
PP 72/48D 2/2A PN I/O module 6FC5311-0AA00-1AA0
USB FlashDrive 64 GB, USB 3.0 6AV6881-0AS42-0AA1
Table 2-3 Ordering data for spare parts / accessories
Spare parts / accessories Article number
Dual fan module 6FC5348-0AA30-3AA0
Spacer for NCU 17x0 6SL3064-1BB00-0AA0
Front cover 6FC5348-0AA30-1AA0
Service area cover 6FC5348-0AA30-2AA0
Cover for optional guide frame 6SL3064-3CB00-0AA0
Dust-protection blanking plug (50 pcs.) for DRIVE-CLiQ interfaces 6SL3066-4CA00-0AA0
PROFIBUS connector with terminating resistor 6ES7972-0BB42-0XA0
Terminal kit, consisting of connectors X122 / X124 / X132 / X142 and dust
cover, blanking plugs for DRIVE-CLiQ interfaces
6SL3064-2CB00-0AA0
Table 2-4 Ordering data of the memory expansion options
Memory expansion options Article number
CNC user memory expansion 6FC5800‑0BD00‑0YB0
PLC main memory each expanded with 1.5 MB program and 5 MB data 6FC5800‑0BD10‑0YB0
System overview
2.4 Ordering data
NCU 1760
Equipment Manual, 02/2020, A5E45627861B AB 21
