Siemens SIPART DR19 Assembly And Installation Guide

SIPART DR19
C73000-M7474-C34-4
36
8.2 6DR2800-8R (R)
Required settings in the basic unit:
R module in slot 2 (AI2): S8
R module in slot 1 (AI3): S9 ≤ 3
4311
3 393
2 ⊥
1 ⊥
4211
3 293
2 ⊥
1 ⊥
UR
Switching:
20 mA 200 Ω
Slot 1 Slot 2
Measuring
range
4
3
2
1
20 mA
1kΩ
500 Ω
200 Ω
(1)
(2)--
--
RE
ΔR
RA
R
I
S
I
s
<<5mAor
R >1k
U
H
+
--
--
--
RE
ΔR
RA
R
Rp
Rp =
R ⋅ 200 Ω
R -- 200 Ω
corresponding R
200 Ω
500 Ω
1kΩ
I
s
=5mA
Calibration:
1. Set measuring range on
module.
2. Input RA: set the digital
indicator with (2) to the star-
ting value.
3. Input RE: set the digital
indicator with (1) to the full
scale value or 20 mA.
I
Designation according to DIN 45140
Terminal blocks
Configuration
switches
