Technical data
12
12.1 HART operating conditions
Rated conditions
Ambient conditions For use indoors and outdoors.
Ambient temperature In hazardous areas, observe the maximum permissible am‐
bient temperature corresponding to the temperature class.
● Permissible ambient temperature for operation
2)3)
-30 ... +80 °C (-22 ... +176 °F)
● Height
2000 m above sea level. At altitudes greater than 2000 m
above sea level, use a suitable power supply.
● Relative humidity
0 ... 100%
Degree of pollution 2
Overvoltage category II
Degree of protection
1)
IP66 / Type 4X to UL 50E
Mounting position Any; pneumatic connections and exhaust air outlet not fac‐
ing up in wet environment, Proper mounting (Page 39)
Vibration resistance
● Harmonic oscillations (sine) according
to EN 60068-2-6/10.2008
3.5 mm (0.14"), 2 ... 27 Hz, 3 cycles/axis
98.1 m/s² (321.84 ft/s²), 27 ... 300 Hz, 3 cycles/axis
● Bumping (half-sine) according to EN 60068-2-27/02.2010
150 m/s² (492 ft/s²), 6 ms, 1000 shocks/axis
● Noise (digitally controlled) according to EN
60068-2-64/04.2009
10 ... 200 Hz; 1 (m/s²)²/Hz (3.28 (ft/s²)²/Hz)
200 ... 500 Hz; 0.3 (m/s²)²/Hz (0.98 (ft/s²)²/Hz)
4 hours/axis
● Recommended range of continuous operation of the entire
control valve
≤ 30 m/s² (98.4 ft/s²) without resonance peak
Climate class According to IEC/EN 60721-3
● Storage
1K5, but -40 ... +80°C (1K5, but -40 ... +176°F)
● Transport
2K4, but -40 ... +80°C (2K4, but -40 ... +176°F)
1)
Max. impact energy 1 Joule for enclosure with inspection window 6DR5..0 and 6DR5..1 or max. 2 Joule for 6DR5..3
2)
At ≤ -10 °C (≤ 14 °F) the display refresh rate of the indicator is limited.
3)
The following applies to order suffix (order code) -Z M40: -40 ... +80 °C (-40 ... +176°F)
12.2 Pneumatic data
Pneumatic data
Auxiliary power (air supply) Compressed air, carbon dioxide (CO
2
), nitrogen (N), noble
gases or cleaned natural gas
● Pressure
1)
1.4 ... 7 bar (20.3 ... 101.5 psi)
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 239
