Procedure
1. Loosen the screw â‘ on the transparent cover â‘¡.
2. Pull the transparent cover â‘¡ up to the front end stop.
3. Tighten every cable in the corresponding terminal.
4. Slide the transparent cover â‘¡ up to the end stop of the basic electronics.
5. Tighten the screw â‘ of the transparent cover â‘¡.
6. Connect the cables of each switch to the lug of the printed circuit board in pairs. Use the
provided cable ties â‘¢ for this purpose.
â‘ Screw
â‘¡ Cover
â‘¢ Cable tie
Figure 5-11 Connecting the cables
Connection
5.2 Electrical wiring
