2 Functions
136
7SD5 Manual
C53000-G1176-C169-1
3710 Dis.Loop L1-2 r OUT Distance Loop L12 selected reverse
3711 Dis.Loop L2-3 r OUT Distance Loop L23 selected reverse
3712 Dis.Loop L3-1 r OUT Distance Loop L31 selected reverse
3713 Dis.Loop L1E<-> OUT Distance Loop L1E selected non-direct.
3714 Dis.Loop L2E<-> OUT Distance Loop L2E selected non-direct.
3715 Dis.Loop L3E<-> OUT Distance Loop L3E selected non-direct.
3716 Dis.Loop L12<-> OUT Distance Loop L12 selected non-direct.
3717 Dis.Loop L23<-> OUT Distance Loop L23 selected non-direct.
3718 Dis.Loop L31<-> OUT Distance Loop L31 selected non-direct.
3719 Dis. forward OUT Distance Pickup FORWARD
3720 Dis. reverse OUT Distance Pickup REVERSE
3741 Dis. Z1 L1E OUT Distance Pickup Z1, Loop L1E
3742 Dis. Z1 L2E OUT Distance Pickup Z1, Loop L2E
3743 Dis. Z1 L3E OUT Distance Pickup Z1, Loop L3E
3744 Dis. Z1 L12 OUT Distance Pickup Z1, Loop L12
3745 Dis. Z1 L23 OUT Distance Pickup Z1, Loop L23
3746 Dis. Z1 L31 OUT Distance Pickup Z1, Loop L31
3747 Dis. Z1B L1E OUT Distance Pickup Z1B, Loop L1E
3748 Dis. Z1B L2E OUT Distance Pickup Z1B, Loop L2E
3749 Dis. Z1B L3E OUT Distance Pickup Z1B, Loop L3E
3750 Dis. Z1B L12 OUT Distance Pickup Z1B, Loop L12
3751 Dis. Z1B L23 OUT Distance Pickup Z1B, Loop L23
3752 Dis. Z1B L31 OUT Distance Pickup Z1B, Loop L31
3755 Dis. Pickup Z2 OUT Distance Pickup Z2
3758 Dis. Pickup Z3 OUT Distance Pickup Z3
3759 Dis. Pickup Z4 OUT Distance Pickup Z4
3760 Dis. Pickup Z5 OUT Distance Pickup Z5
3771 Dis.Time Out T1 OUT DistanceTime Out T1
3774 Dis.Time Out T2 OUT DistanceTime Out T2
3777 Dis.Time Out T3 OUT DistanceTime Out T3
3778 Dis.Time Out T4 OUT DistanceTime Out T4
3779 Dis.Time Out T5 OUT DistanceTime Out T5
3780 Dis.TimeOut T1B OUT DistanceTime Out T1B
3781 Dis.TimeOut Tfw OUT DistanceTime Out Forward PICKUP
3782 Dis.TimeOut Tnd OUT DistanceTime Out Non-directional PICKUP
3801 Dis.Gen. Trip OUT Distance protection: General trip
3802 Dis.Trip 1pL1 OUT Distance TRIP command - Only Phase L1
3803 Dis.Trip 1pL2 OUT Distance TRIP command - Only Phase L2
3804 Dis.Trip 1pL3 OUT Distance TRIP command - Only Phase L3
3805 Dis.Trip 3p OUT Distance TRIP command Phases L123
3811 Dis.TripZ1/1p OUT Distance TRIP single-phase Z1
3813 Dis.TripZ1B1p OUT Distance TRIP single-phase Z1B
3816 Dis.TripZ2/1p OUT Distance TRIP single-phase Z2
3817 Dis.TripZ2/3p OUT Distance TRIP 3phase in Z2
3818 Dis.TripZ3/T3 OUT Distance TRIP 3phase in Z3
3819 Dis.Trip FD-> OUT Dist.: Trip by fault detection, forward
No. Information Type of In-
formation
Comments
