A.4 Default Settings
611
7SD5 Manual
C53000-G1176-C169-1
A.4.3 Binary Output
Table A-3 Output relay presettings for all devices and ordering variants
1)
only devices with 2 protection data interfaces
2)
only devices with three-pole tripping
3)
only devices with single-pole and three-pole tripping
4)
only devices with automatic reclosure function
Binary Output Vorrangierte
Funktion
Function No. Description
BO1 Relay PICKUP 501 Relay PICKUP
BO2 PI1 Data fault 3229 Prot Int 1: Reception of faulty data
BO3 PI2 Data fault 3231 Prot Int 2: Reception of faulty data
1)
BO4 Relay TRIP 511 Relay GENERAL TRIP command
2)
Relay TRIP 1pL1 512 Relay TRIP command - Only Phase
L1
3)
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
3)
BO5 Relay TRIP 511 Relay GENERAL TRIP command
2)
Relay TRIP 1pL2 513 Relay TRIP command - Only Phase
L2
3)
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
3)
BO6 no presetting - -
2)
Relay TRIP 1pL3 514 Relay TRIP command - Only Phase
L3
3)
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
3)
BO7 AR CLOSE Cmd. 2851 AR: Close command
4)
BO8 Diff block 3148 Diff: Differential protection is blocked
BO9 AR not ready 2784 AR: Auto-reclose is not ready
4)
BO10 Test Diff. 3190 Diff: Set Teststate of Diff. protection
TestDiff.remote 3192 Diff: Remote relay in Teststate
BO11 Emer. mode 2054 Emergency mode
BO12 Alarm Sum Event 160 Alarm Summary Event
BO13 Relay TRIP 511 Relay GENERAL TRIP command
2)
Relay TRIP 1pL1 512 Relay TRIP command - Only Phase
L1
3)
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
3)
BO14 Relay TRIP 511 Relay GENERAL TRIP command
2)
Relay TRIP 1pL2 513 Relay TRIP command - Only Phase
L2
3)
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
3)
BO15 no presetting - -
2)
Relay TRIP 1pL3 514 Relay TRIP command - Only Phase
L3
3)
Relay TRIP 3ph. 515 Relay TRIP command Phases L123
3)
