2.14 Backup Time Overcurrent Protection
283
7SD5 Manual
C53000-G1176-C169-1
7161 O/C PICKUP OUT Backup O/C PICKED UP
7162 O/C Pickup L1 OUT Backup O/C PICKUP L1
7163 O/C Pickup L2 OUT Backup O/C PICKUP L2
7164 O/C Pickup L3 OUT Backup O/C PICKUP L3
7165 O/C Pickup E OUT Backup O/C PICKUP EARTH
7171 O/C PU only E OUT Backup O/C Pickup - Only EARTH
7172 O/C PU 1p. L1 OUT Backup O/C Pickup - Only L1
7173 O/C Pickup L1E OUT Backup O/C Pickup L1E
7174 O/C PU 1p. L2 OUT Backup O/C Pickup - Only L2
7175 O/C Pickup L2E OUT Backup O/C Pickup L2E
7176 O/C Pickup L12 OUT Backup O/C Pickup L12
7177 O/C Pickup L12E OUT Backup O/C Pickup L12E
7178 O/C PU 1p. L3 OUT Backup O/C Pickup - Only L3
7179 O/C Pickup L3E OUT Backup O/C Pickup L3E
7180 O/C Pickup L31 OUT Backup O/C Pickup L31
7181 O/C Pickup L31E OUT Backup O/C Pickup L31E
7182 O/C Pickup L23 OUT Backup O/C Pickup L23
7183 O/C Pickup L23E OUT Backup O/C Pickup L23E
7184 O/C Pickup L123 OUT Backup O/C Pickup L123
7185 O/C PickupL123E OUT Backup O/C Pickup L123E
7191 O/C PICKUP I>> OUT Backup O/C Pickup I>>
7192 O/C PICKUP I> OUT Backup O/C Pickup I>
7193 O/C PICKUP Ip OUT Backup O/C Pickup Ip
7201 I-STUB PICKUP OUT O/C I-STUB Pickup
7211 O/C TRIP OUT Backup O/C General TRIP command
7212 O/C TRIP 1p.L1 OUT Backup O/C TRIP - Only L1
7213 O/C TRIP 1p.L2 OUT Backup O/C TRIP - Only L2
7214 O/C TRIP 1p.L3 OUT Backup O/C TRIP - Only L3
7215 O/C TRIP L123 OUT Backup O/C TRIP Phases L123
7221 O/C TRIP I>> OUT Backup O/C TRIP I>>
7222 O/C TRIP I> OUT Backup O/C TRIP I>
7223 O/C TRIP Ip OUT Backup O/C TRIP Ip
7235 I-STUB TRIP OUT O/C I-STUB TRIP
No. Information Type of In-
formation
Comments
