2.15 Automatic Reclosure Function (optional)
313
7SD5 Manual
C53000-G1176-C169-1
2842 AR Tdead 2pFlt OUT AR dead time after 2phase fault running
2843 AR Tdead 3pFlt OUT AR dead time after 3phase fault running
2844 AR 1stCyc. run. OUT AR 1st cycle running
2845 AR 2ndCyc. run. OUT AR 2nd cycle running
2846 AR 3rdCyc. run. OUT AR 3rd cycle running
2847 AR 4thCyc. run. OUT AR 4th or higher cycle running
2848 AR ADT run. OUT AR cycle is running in ADT mode
2851 AR CLOSE Cmd. OUT AR: Close command
2852 AR Close1.Cyc1p OUT AR: Close command after 1pole, 1st cycle
2853 AR Close1.Cyc3p OUT AR: Close command after 3pole, 1st cycle
2854 AR Close 2.Cyc OUT AR: Close command 2nd cycle (and higher)
2861 AR T-Recl. run. OUT AR: Reclaim time is running
2862 AR successful OUT AR successful
2863 Definitive Trip OUT Definitive TRIP
2864 AR 1p Trip Perm OUT AR: 1pole trip permitted by internal AR
2865 AR Sync.Request OUT AR: Synchro-check request
2871 AR TRIP 3pole OUT AR: TRIP command 3pole
2889 AR 1.CycZoneRel OUT AR 1st cycle zone extension release
2890 AR 2.CycZoneRel OUT AR 2nd cycle zone extension release
2891 AR 3.CycZoneRel OUT AR 3rd cycle zone extension release
2892 AR 4.CycZoneRel OUT AR 4th cycle zone extension release
2893 AR Zone Release OUT AR zone extension (general)
2894 AR Remote Close OUT AR Remote close signal send
No. Information Type of In-
formation
Comments
