2.19 Fault Locator
357
7SD5 Manual
C53000-G1176-C169-1
1136 Xpri single. = VI X (primary, single ended)
1137 Rsec single. = VI R (secondary single ended)
1138 Xsec single. = VI X (secondary single ended)
1143 BCD d[1%] OUT BCD Fault location [1%]
1144 BCD d[2%] OUT BCD Fault location [2%]
1145 BCD d[4%] OUT BCD Fault location [4%]
1146 BCD d[8%] OUT BCD Fault location [8%]
1147 BCD d[10%] OUT BCD Fault location [10%]
1148 BCD d[20%] OUT BCD Fault location [20%]
1149 BCD d[40%] OUT BCD Fault location [40%]
1150 BCD d[80%] OUT BCD Fault location [80%]
1151 BCD d[100%] OUT BCD Fault location [100%]
1152 BCD dist. VALID OUT BCD Fault location valid
No. Information Type of In-
formation
Comments
