2.21 Thermal Overload Protection
377
7SD5 Manual
C53000-G1176-C169-1
1513 Th.O/L ACTIVE OUT Thermal Overload Protection ACTIVE
1515 Th.O/L I Alarm OUT Th. Overload: Current Alarm (I alarm)
1516 Th.O/L Θ Alarm OUT Th. Overload Alarm: Near Thermal Trip
1517 Th.O/L Pickup OUT Th. Overload Pickup before trip
1521 Th.O/L TRIP OUT Th. Overload TRIP command
No. Information Type of In-
formation
Comments
