2 Functions
426
7SD5 Manual
C53000-G1176-C169-1
973 R L31= MV R L31
974 X L1E= MV X L1E
975 X L2E= MV X L2E
976 X L3E= MV X L3E
977 X L12= MV X L12
978 X L23= MV X L23
979 X L31= MV X L31
7731 Φ IL1L2= MV PHI IL1L2 (local)
7732 Φ IL2L3= MV PHI IL2L3 (local)
7733 Φ IL3L1= MV PHI IL3L1 (local)
7734 Φ UL1L2= MV PHI UL1L2 (local)
7735 Φ UL2L3= MV PHI UL2L3 (local)
7736 Φ UL3L1= MV PHI UL3L1 (local)
7737 Φ UIL1= MV PHI UIL1 (local)
7738 Φ UIL2= MV PHI UIL2 (local)
7739 Φ UIL3= MV PHI UIL3 (local)
No. Information Type of In-
formation
Comments
