2.24 Ancillary Functions
433
7SD5 Manual
C53000-G1176-C169-1
844 I1dmdMax MVT I1 (positive sequence) Demand Maximum
845 PdMin= MVT Active Power Demand Minimum
846 PdMax= MVT Active Power Demand Maximum
847 QdMin= MVT Reactive Power Demand Minimum
848 QdMax= MVT Reactive Power Demand Maximum
849 SdMin= MVT Apparent Power Demand Minimum
850 SdMax= MVT Apparent Power Demand Maximum
851 IL1Min= MVT I L1 Minimum
852 IL1Max= MVT I L1 Maximum
853 IL2Min= MVT I L2 Mimimum
854 IL2Max= MVT I L2 Maximum
855 IL3Min= MVT I L3 Minimum
856 IL3Max= MVT I L3 Maximum
857 I1 Min= MVT Positive Sequence Minimum
858 I1 Max= MVT Positive Sequence Maximum
859 UL1EMin= MVT U L1E Minimum
860 UL1EMax= MVT U L1E Maximum
861 UL2EMin= MVT U L2E Minimum
862 UL2EMax= MVT U L2E Maximum
863 UL3EMin= MVT U L3E Minimum
864 UL3EMax= MVT U L3E Maximum
865 UL12Min= MVT U L12 Minimum
867 UL12Max= MVT U L12 Maximum
868 UL23Min= MVT U L23 Minimum
869 UL23Max= MVT U L23 Maximum
870 UL31Min= MVT U L31 Minimum
871 UL31Min= MVT U L31 Maximum
874 U1 Min = MVT U1 (positive sequence) Voltage Minimum
875 U1 Max = MVT U1 (positive sequence) Voltage Maximum
880 SMin= MVT Apparent Power Minimum
881 SMax= MVT Apparent Power Maximum
882 fMin= MVT Frequency Minimum
883 fMax= MVT Frequency Maximum
1040 Pmin Forw= MVT Active Power Minimum Forward
1041 Pmax Forw= MVT Active Power Maximum Forward
1042 Pmin Rev = MVT Active Power Minimum Reverse
1043 Pmax Rev = MVT Active Power Maximum Reverse
1044 Qmin Forw= MVT Reactive Power Minimum Forward
1045 Qmax Forw= MVT Reactive Power Maximum Forward
1046 Qmin Rev = MVT Reactive Power Minimum Reverse
1047 Qmax Rev = MVT Reactive Power Maximum Reverse
1048 PFminForw= MVT Power Factor Minimum Forward
1049 PFmaxForw= MVT Power Factor Maximum Forward
1050 PFmin Rev= MVT Power Factor Minimum Reverse
1051 PFmax Rev= MVT Power Factor Maximum Reverse
No. Information Type of In-
formation
Comments
