4 Technical Data
524
7SD5 Manual
C53000-G1176-C169-1
System interface (optional)
RS232/RS485/FO
Profibus FMS RS485/Profibus FMS FO
Profibus DP RS485/Profibus DP FO
DNP 3.0 RS 485
DNP 3.0 FO
Acc. to ordered variant
Isolated interface for data transfer to a
control terminal
RS232
Connection for panel flush mounting
housing
Rear panel, slot „B“,
9-pole D-subminiature female connector
Connection for panel surface mounting housing
Up to .../BB At two-tier terminal on the housing bottom
../CC and higher In console housing at device bottom
9-pole D-subminiature female connector
Test voltage 500 V; 50 Hz
Transmission speed Min. 4800 Baud; max. 38400 Baud
Factory setting 19200 Baud
Transmission distance Max. 15 m (0.93 miles)
RS485
Connection for panel flush mounting
housing
Rear panel, slot „B“,
9-pole D-subminiature female connector
Connection for panel surface mounting housing
Up to .../BB At two-tier terminal on the housing bottom
../CC and higher In console housing at device bottom
9-pole D-subminiature female connector
Test voltage 500 V; 50 Hz
Transmission speed Min. 4800 Bd, max. 38400 Bd
Factory setting 19200 Bd
Transmission distance Max. 1 km (0.93 miles)
Fibre optic cable (FO)
FO connector type ST connector
Connection for panel flush mounting
housing
Rear panel, mounting location „B“
Connection for panel surface mounting
housing
In console housing at device bottom
Optical wavelength λ = 820 nm
Laser class 1 according to EN 60825-1/-2 Using glass fibre 50/125 µm or
Using glass fibre 62.5/125 µm
Permissible optical signal attenuation Max. 8 dB, with glass fibre 62.5/125 µm
Transmission distance Max. 1.5 km (0.93 miles)
Character idle state Selectable, factory setting „Light off“
Profibus RS 485 (FMS and DP)
In console housing on bottom
9-pole D-subminiature female
connector
Connection for panel flush mounting
housing
Rear panel, slot „B“,
9-pole D-subminiature female connector
Connection for panel surface mounting housing
Test voltage 500 V; 50 Hz
Transmission speed Up to 12 MBaud
Transmission distance 1.000 m (1640 ft.) at ≤ 93.75 kBd
500 m (1640 ft.) at ≤ 187.5 kBd
200 m (328 ft.) at ≤ 1.5 MBaud
100 m (328 ft.) at ≤ 12 MBaud
