A.4 Default Settings
613
7SD5 Manual
C53000-G1176-C169-1
Graphic Display
Spontaneous Fault
Indication of the 4-
Line Display
The spontaneous annunciations on devices with 4-line display serve to display the
most important data about a fault. They appear automatically in the display after
general interrogation of the device, in the sequence shown in the following Figure.
Figure A-20 Spontaneous fault indication display
Spontaneous Fault
Annunciations of
the Graphic Display
All devices featuring a graphic display allow you to select whether or not to view auto-
matically the most important fault data on the display after a general interrogation.
The information is shown in the display in the following order:
• Relay PICKUP:
• S/E/F TRIP
•PU Time=:
•Trip time=:
• Fault Location
