A.7 Settings
623
7SD5 Manual
C53000-G1176-C169-1
1612 R(Z2) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 2.500 Ω R(Z2), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 0.500 Ω
1613 X(Z2) Dis. Quadril. 1A 0.050 .. 600.000 Ω 5.000 Ω X(Z2), Reactance
5A 0.010 .. 120.000 Ω 1.000 Ω
1614 RE(Z2) Ø-E Dis. Quadril. 1A 0.050 .. 600.000 Ω 5.000 Ω RE(Z2), Resistance for ph-e
faults
5A 0.010 .. 120.000 Ω 1.000 Ω
1615 T2-1phase Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.30 sec T2-1phase, delay for single
phase faults
1616 T2-multi-phase Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.30 sec T2multi-ph, delay for multi phase
faults
1617A Trip 1pole Z2 Dis. General
Dis. Quadril.
Dis. MHO
NO
YES
NO Single pole trip for faults in Z2
1621 Op. mode Z3 Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Reverse Operating mode Z3
1622 R(Z3) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 5.000 Ω R(Z3), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 1.000 Ω
1623 X(Z3) Dis. Quadril. 1A 0.050 .. 600.000 Ω 10.000 Ω X(Z3), Reactance
5A 0.010 .. 120.000 Ω 2.000 Ω
1624 RE(Z3) Ø-E Dis. Quadril. 1A 0.050 .. 600.000 Ω 10.000 Ω RE(Z3), Resistance for ph-e
faults
5A 0.010 .. 120.000 Ω 2.000 Ω
1625 T3 DELAY Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.60 sec T3 delay
1631 Op. mode Z4 Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Non-Directional Operating mode Z4
1632 R(Z4) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω R(Z4), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 2.400 Ω
1633 X(Z4) Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω X(Z4), Reactance
5A 0.010 .. 120.000 Ω 2.400 Ω
1634 RE(Z4) Ø-E Dis. Quadril. 1A 0.050 .. 250.000 Ω 12.000 Ω RE(Z4), Resistance for ph-e
faults
5A 0.010 .. 50.000 Ω 2.400 Ω
1635 T4 DELAY Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.90 sec T4 delay
1641 Op. mode Z5 Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode Z5
1642 R(Z5) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω R(Z5), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 2.400 Ω
1643 X(Z5)+ Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω X(Z5)+, Reactance for Forward
direction
5A 0.010 .. 120.000 Ω 2.400 Ω
1644 RE(Z5) Ø-E Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω RE(Z5), Resistance for ph-e
faults
5A 0.010 .. 120.000 Ω 2.400 Ω
1645 T5 DELAY Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.90 sec T5 delay
1646 X(Z5)- Dis. Quadril. 1A 0.050 .. 600.000 Ω 4.000 Ω X(Z5)-, Reactance for Reverse
direction
5A 0.010 .. 120.000 Ω 0.800 Ω
1651 Op. mode Z1B Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Forward Operating mode Z1B (overrreach
zone)
1652 R(Z1B) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 1.500 Ω R(Z1B), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 0.300 Ω
Addr. Parameter Function C Setting Options Default Setting Comments
