A Appendix
632
7SD5 Manual
C53000-G1176-C169-1
3483 4.AR: START Auto Reclose YES
NO
NO AR start allowed in this cycle
3484 4.AR: T-ACTION Auto Reclose 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3486 4.AR Tdead 1Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3487 4.AR Tdead 2Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3488 4.AR Tdead 3Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3489 4.AR Tdead1Trip Auto Reclose 0.01 .. 1800.00 sec; ∞∞sec Dead time after 1pole trip
3490 4.AR Tdead3Trip Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3491 4.AR: Tdead EV. Auto Reclose 0.01 .. 1800.00 sec 1.20 sec Dead time after evolving fault
3492 4.AR: CB? CLOSE Auto Reclose YES
NO
NO CB ready interrogation before re-
closing
3493 4.AR SynRequest Auto Reclose YES
NO
NO Request for synchro-check after
3pole AR
3501 FCT Synchronism Sync. Check ON
OFF
ON:w/o CloseCmd
ON Synchronism and Voltage Check
function
3502 Dead Volt. Thr. Sync. Check 1 .. 60 V 5 V Voltage threshold dead line / bus
3503 Live Volt. Thr. Sync. Check 20 .. 125 V 90 V Voltage threshold live line / bus
3504 Umax Sync. Check 20 .. 140 V 110 V Maximum permissible voltage
3507 T-SYN. DURATION Sync. Check 0.01 .. 600.00 sec; ∞ 1.00 sec Maximum duration of synchro-
nism-check
3508 T SYNC-STAB Sync. Check 0.00 .. 30.00 sec 0.00 sec Synchronous condition stability
timer
3509 SyncCB Sync. Check (Setting options depend
on configuration)
None Synchronizable circuit breaker
3510 Op.mode with AR Sync. Check with T-CB close
w/o T-CB close
w/o T-CB close Operating mode with AR
3511 Max. Volt. Diff Sync. Check 1.0 .. 40.0 V 2.0 V Maximum voltage difference
3512 Max. Freq. Diff Sync. Check 0.03 .. 2.00 Hz 0.10 Hz Maximum frequency difference
3513 Max. Angle Diff Sync. Check 2 .. 80 ° 10 ° Maximum angle difference
3515A SYNC-CHECK Sync. Check YES
NO
YES Live bus / live line and Sync
before AR
3516 Usync> U-line< Sync. Check YES
NO
NO Live bus / dead line check before
AR
3517 Usync< U-line> Sync. Check YES
NO
NO Dead bus / live line check before
AR
3518 Usync< U-line< Sync. Check YES
NO
NO Dead bus / dead line check
before AR
3519 OVERRIDE Sync. Check YES
NO
NO Override of any check before AR
3530 Op.mode with MC Sync. Check with T-CB close
w/o T-CB close
w/o T-CB close Operating mode with Man.Cl
3531 MC maxVolt.Diff Sync. Check 1.0 .. 40.0 V 2.0 V Maximum voltage difference
3532 MC maxFreq.Diff Sync. Check 0.03 .. 2.00 Hz 0.10 Hz Maximum frequency difference
3533 MC maxAngleDiff Sync. Check 2 .. 80 ° 10 ° Maximum angle difference
3535A MC SYNCHR Sync. Check YES
NO
YES Live bus / live line and Sync
before MC
3536 MC Usyn> Uline< Sync. Check YES
NO
NO Live bus / dead line check before
Man.Cl
3537 MC Usyn< Uline> Sync. Check YES
NO
NO Dead bus / live line check before
Man.Cl
3538 MC Usyn< Uline< Sync. Check YES
NO
NO Dead bus / dead line check
before Man.Cl
3539 MC O/RIDE Sync. Check YES
NO
NO Override of any check before
Man.Cl
3601 O/U FREQ. f1 Frequency Prot. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only Over/Under Frequency Protec-
tion stage f1
3602 f1 PICKUP Frequency Prot. 45.50 .. 54.50 Hz 49.50 Hz f1 Pickup
3603 f1 PICKUP Frequency Prot. 55.50 .. 64.50 Hz 59.50 Hz f1 Pickup
3604 T f1 Frequency Prot. 0.00 .. 600.00 sec 60.00 sec T f1 Time Delay
Addr. Parameter Function C Setting Options Default Setting Comments
