Siemens siprotec 7SD5 User Manual

A Appendix
658
7SD5 Manual
C53000-G1176-C169-1
3548 Remote Trip 4 received
(RemoteTrip4 rec)
Remote Signals OUT on
off
* * LED BO 93 157 1 Yes
3549 >Remote Signal 1 input (>Rem.
Signal 1)
Remote Signals SP on
off
**LEDBIBO
3550 >Remote Signal 2 input
(>Rem.Signal 2)
Remote Signals SP on
off
**LEDBIBO
3551 >Remote Signal 3 input
(>Rem.Signal 3)
Remote Signals SP on
off
**LEDBIBO
3552 >Remote Signal 4 input
(>Rem.Signal 4)
Remote Signals SP on
off
**LEDBIBO
3553 >Remote Signal 5 input
(>Rem.Signal 5)
Remote Signals SP on
off
**LEDBIBO
3554 >Remote Signal 6 input
(>Rem.Signal 6)
Remote Signals SP on
off
**LEDBIBO
3555 >Remote Signal 7 input
(>Rem.Signal 7)
Remote Signals SP on
off
**LEDBIBO
3556 >Remote Signal 8 input
(>Rem.Signal 8)
Remote Signals SP on
off
**LEDBIBO
3557 >Remote Signal 9 input
(>Rem.Signal 9)
Remote Signals SP on
off
**LEDBIBO
3558 >Remote Signal 10 input
(>Rem.Signal10)
Remote Signals SP on
off
**LEDBIBO
3559 >Remote Signal 11 input
(>Rem.Signal11)
Remote Signals SP on
off
**LEDBIBO
3560 >Remote Signal 12 input
(>Rem.Signal12)
Remote Signals SP on
off
**LEDBIBO
3561 >Remote Signal 13 input
(>Rem.Signal13)
Remote Signals SP on
off
**LEDBIBO
3562 >Remote Signal 14 input
(>Rem.Signal14)
Remote Signals SP on
off
**LEDBIBO
3563 >Remote Signal 15 input
(>Rem.Signal15)
Remote Signals SP on
off
**LEDBIBO
3564 >Remote Signal 16 input
(>Rem.Signal16)
Remote Signals SP on
off
**LEDBIBO
3565 >Remote Signal 17 input
(>Rem.Signal17)
Remote Signals SP on
off
**LEDBIBO
3566 >Remote Signal 18 input
(>Rem.Signal18)
Remote Signals SP on
off
**LEDBIBO
3567 >Remote Signal 19 input
(>Rem.Signal19)
Remote Signals SP on
off
**LEDBIBO
3568 >Remote Signal 20 input
(>Rem.Signal20)
Remote Signals SP on
off
**LEDBIBO
3569 >Remote Signal 21 input
(>Rem.Signal21)
Remote Signals SP on
off
**LEDBIBO
3570 >Remote Signal 22 input
(>Rem.Signal22)
Remote Signals SP on
off
**LEDBIBO
3571 >Remote Signal 23 input
(>Rem.Signal23)
Remote Signals SP on
off
**LEDBIBO
3572 >Remote Signal 24 input
(>Rem.Signal24)
Remote Signals SP on
off
**LEDBIBO
3573 Remote signal 1 received
(Rem.Sig 1recv)
Remote Signals OUT on
off
* * LED BO 93 158 1 Yes
3574 Remote signal 2 received
(Rem.Sig 2recv)
Remote Signals OUT on
off
* * LED BO 93 159 1 Yes
3575 Remote signal 3 received
(Rem.Sig 3recv)
Remote Signals OUT on
off
* * LED BO 93 160 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
