A Appendix
660
7SD5 Manual
C53000-G1176-C169-1
3620 >BLOCK Z5 for ph-e loops
(>BLOCK Z5 Ph-E)
Dis. General SP ON
OFF
**LEDBIBO28201Yes
3651 Distance is switched off (Dist.
OFF)
Dis. General OUT ON
OFF
**LEDBO28511Yes
3652 Distance is BLOCKED (Dist.
BLOCK)
Dis. General OUT ON
OFF
ON
OFF
* LED BO 28 52 1 Yes
3653 Distance is ACTIVE (Dist.
ACTIVE)
Dis. General OUT * * * LED BO 28 53 1 Yes
3654 Setting error K0(Z1) or Angle
K0(Z1) (Dis.ErrorK0(Z1))
Dis. General OUT ON
OFF
**LEDBO
3655 Setting error K0(>Z1) or Angle
K0(>Z1) (DisErrorK0(>Z1))
Dis. General OUT ON
OFF
**LEDBO
3671 Distance PICKED UP (Dis.
PICKUP)
Dis. General OUT * OFF * LED BO 28 71 2 Yes
3672 Distance PICKUP L1 (Dis.Pickup
L1)
Dis. General OUT * * m LED BO 28 72 2 Yes
3673 Distance PICKUP L2 (Dis.Pickup
L2)
Dis. General OUT * * m LED BO 28 73 2 Yes
3674 Distance PICKUP L3 (Dis.Pickup
L3)
Dis. General OUT * * m LED BO 28 74 2 Yes
3675 Distance PICKUP Earth
(Dis.Pickup E)
Dis. General OUT * * * LED BO 28 75 2 Yes
3681 Distance Pickup Phase L1 (only)
(Dis.Pickup 1pL1)
Dis. General OUT * ON * LED BO 28 81 2 No
3682 Distance Pickup L1E (Dis.Pickup
L1E)
Dis. General OUT * ON * LED BO 28 82 2 No
3683 Distance Pickup Phase L2 (only)
(Dis.Pickup 1pL2)
Dis. General OUT * ON * LED BO 28 83 2 No
3684 Distance Pickup L2E (Dis.Pickup
L2E)
Dis. General OUT * ON * LED BO 28 84 2 No
3685 Distance Pickup L12 (Dis.Pickup
L12)
Dis. General OUT * ON * LED BO 28 85 2 No
3686 Distance Pickup L12E (Dis.Pick-
up L12E)
Dis. General OUT * ON * LED BO 28 86 2 No
3687 Distance Pickup Phase L3 (only)
(Dis.Pickup 1pL3)
Dis. General OUT * ON * LED BO 28 87 2 No
3688 Distance Pickup L3E (Dis.Pickup
L3E)
Dis. General OUT * ON * LED BO 28 88 2 No
3689 Distance Pickup L31 (Dis.Pickup
L31)
Dis. General OUT * ON * LED BO 28 89 2 No
3690 Distance Pickup L31E (Dis.Pick-
up L31E)
Dis. General OUT * ON * LED BO 28 90 2 No
3691 Distance Pickup L23 (Dis.Pickup
L23)
Dis. General OUT * ON * LED BO 28 91 2 No
3692 Distance Pickup L23E (Dis.Pick-
up L23E)
Dis. General OUT * ON * LED BO 28 92 2 No
3693 Distance Pickup L123 (Dis.Pick-
up L123)
Dis. General OUT * ON * LED BO 28 93 2 No
3694 Distance Pickup123E
(Dis.Pickup123E)
Dis. General OUT * ON * LED BO 28 94 2 No
3695 Dist.: Phi phase L1 Pickup (Dis
Pickup ϕ L1)
Dis. General OUT * * * LED BO
3696 Dist.: Phi phase L2 Pickup (Dis
Pickup ϕ L2)
Dis. General OUT * * * LED BO
3697 Dist.: Phi phase L3 Pickup (Dis
Pickup ϕ L3)
Dis. General OUT * * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
