A Appendix
662
7SD5 Manual
C53000-G1176-C169-1
3749 Distance Pickup Z1B, Loop L3E
(Dis. Z1B L3E)
Dis. General OUT * * * LED BO
3750 Distance Pickup Z1B, Loop L12
(Dis. Z1B L12)
Dis. General OUT * * * LED BO
3751 Distance Pickup Z1B, Loop L23
(Dis. Z1B L23)
Dis. General OUT * * * LED BO
3752 Distance Pickup Z1B, Loop L31
(Dis. Z1B L31)
Dis. General OUT * * * LED BO
3755 Distance Pickup Z2 (Dis. Pickup
Z2)
Dis. General OUT * * * LED BO
3758 Distance Pickup Z3 (Dis. Pickup
Z3)
Dis. General OUT * * * LED BO
3759 Distance Pickup Z4 (Dis. Pickup
Z4)
Dis. General OUT * * * LED BO
3760 Distance Pickup Z5 (Dis. Pickup
Z5)
Dis. General OUT * * * LED BO
3771 DistanceTime Out T1 (Dis.Time
Out T1)
Dis. General OUT * * * LED BO 28 171 2 No
3774 DistanceTime Out T2 (Dis.Time
Out T2)
Dis. General OUT * * * LED BO 28 172 2 No
3777 DistanceTime Out T3 (Dis.Time
Out T3)
Dis. General OUT * * * LED BO 28 173 2 No
3778 DistanceTime Out T4 (Dis.Time
Out T4)
Dis. General OUT * * * LED BO 28 174 2 No
3779 DistanceTime Out T5 (Dis.Time
Out T5)
Dis. General OUT * * * LED BO 28 175 2 No
3780 DistanceTime Out T1B (Dis.Tim-
eOut T1B)
Dis. General OUT * * * LED BO 28 180 2 No
3781 DistanceTime Out Forward
PICKUP (Dis.TimeOut Tfw)
Dis. General OUT * * * LED BO 28 160 2 No
3782 DistanceTime Out Non-direction-
al PICKUP (Dis.TimeOut Tnd)
Dis. General OUT * * * LED BO 28 161 2 No
3801 Distance protection: General trip
(Dis.Gen. Trip)
Dis. General OUT * * * LED BO 28 201 2 No
3802 Distance TRIP command - Only
Phase L1 (Dis.Trip 1pL1)
Dis. General OUT * ON * LED BO 28 202 2 No
3803 Distance TRIP command - Only
Phase L2 (Dis.Trip 1pL2)
Dis. General OUT * ON * LED BO 28 203 2 No
3804 Distance TRIP command - Only
Phase L3 (Dis.Trip 1pL3)
Dis. General OUT * ON * LED BO 28 204 2 No
3805 Distance TRIP command Phases
L123 (Dis.Trip 3p)
Dis. General OUT * ON * LED BO 28 205 2 No
3811 Distance TRIP single-phase Z1
(Dis.TripZ1/1p)
Dis. General OUT * * * LED BO 28 211 2 No
3813 Distance TRIP single-phase Z1B
(Dis.TripZ1B1p)
Dis. General OUT * * * LED BO 28 213 2 No
3816 Distance TRIP single-phase Z2
(Dis.TripZ2/1p)
Dis. General OUT * * * LED BO 28 216 2 No
3817 Distance TRIP 3phase in Z2
(Dis.TripZ2/3p)
Dis. General OUT * * * LED BO 28 217 2 No
3818 Distance TRIP 3phase in Z3
(Dis.TripZ3/T3)
Dis. General OUT * * * LED BO 28 218 2 No
3819 Dist.: Trip by fault detection,
forward (Dis.Trip FD->)
Dis. General OUT * * * LED BO 28 219 2 No
3820 Dist.: Trip by fault detec, rev/non-
dir. (Dis.Trip <->)
Dis. General OUT * * * LED BO 28 220 2 No
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
