7SD5 Manual
C53000-G1176-C169-1
4052 Dis. Teleprotection is switched
OFF (Dis.Telep. OFF)
Teleprot. Dist. OUT ON
OFF
**LEDBO
4054 Dis. Telep. Carrier signal received
(Dis.T.Carr.rec.)
Teleprot. Dist. OUT * * * LED BO 29 54 2 No
4055 Dis. Telep. Carrier CHANNEL
FAILURE (Dis.T.Carr.Fail)
Teleprot. Dist. OUT * * * LED BO 29 55 1 Yes
4056 Dis. Telep. Carrier SEND signal
(Dis.T.SEND)
Teleprot. Dist. OUT on on * LED BO 29 56 2 No
4057 Dis. Telep. Carrier SEND signal,
L1 (Dis.T.SEND L1)
Teleprot. Dist. OUT * * * LED BO
4058 Dis. Telep. Carrier SEND signal,
L2 (Dis.T.SEND L2)
Teleprot. Dist. OUT * * * LED BO
4059 Dis. Telep. Carrier SEND signal,
L3 (Dis.T.SEND L3)
Teleprot. Dist. OUT * * * LED BO
4060 Dis.Tele.Blocking: Send signal
with jump (DisJumpBlocking)
Teleprot. Dist. OUT * * * LED BO 29 60 2 No
4068 Dis. Telep. Transient Blocking
(Dis.T.Trans.Blk)
Teleprot. Dist. OUT * ON * LED BO 29 68 2 No
4070 Dis. Tele.Blocking: carrier STOP
signal (Dis.T.BL STOP)
Teleprot. Dist. OUT * ON * LED BO 29 70 2 No
4080 Dis. Tele.Unblocking: FAILURE
Channel 1 (Dis.T.UB Fail1)
Teleprot. Dist. OUT on
off
**LEDBO29801Yes
4081 Dis. Tele.Unblocking: FAILURE
Channel 2 (Dis.T.UB Fail2)
Teleprot. Dist. OUT on
off
**LEDBO29811Yes
4082 DisTel Blocking: carrier STOP
signal, L1 (Dis.T.BL STOPL1)
Teleprot. Dist. OUT * * * LED BO
4083 DisTel Blocking: carrier STOP
signal, L2 (Dis.T.BL STOPL2)
Teleprot. Dist. OUT * * * LED BO
4084 DisTel Blocking: carrier STOP
signal, L3 (Dis.T.BL STOPL3)
Teleprot. Dist. OUT * * * LED BO
4160 >BLOCK Power Swing detection
(>Pow. Swing BLK)
Power Swing SP ON
OFF
ON
OFF
* LED BI BO
4163 Power Swing unstable (P.Swing
unstab.)
Power Swing OUT ON ON * LED BO
4164 Power Swing detected (Power
Swing)
Power Swing OUT ON
OFF
ON
OFF
* LED BO 29 164 1 Yes
4166 Power Swing TRIP command
(Pow. Swing TRIP)
Power Swing OUT ON ON * LED BO 29 166 1 No
4167 Power Swing detected in L1
(Pow. Swing L1)
Power Swing OUT ON
OFF
ON
OFF
*LED BO
4168 Power Swing detected in L2
(Pow. Swing L2)
Power Swing OUT ON
OFF
ON
OFF
*LED BO
4169 Power Swing detected in L3
(Pow. Swing L3)
Power Swing OUT ON
OFF
ON
OFF
*LED BO
4203 >BLOCK Weak Infeed (>BLOCK
Weak Inf)
Weak Infeed SP * * * LED BI BO
4204 >BLOCK delayed Weak Infeed
stage (>BLOCK del. WI)
Weak Infeed SP ON
OFF
ON
OFF
* LED BI BO
4205 >Reception (channel) for Weak
Infeed OK (>WI rec. OK)
Weak Infeed SP ON
OFF
ON
OFF
* LED BI BO
4206 >Receive signal for Weak Infeed
(>WI reception)
Weak Infeed SP ON
OFF
ON
OFF
* LED BI BO
4221 Weak Infeed is switched OFF
(WeakInf. OFF)
Weak Infeed OUT ON
OFF
**LEDBO25211Yes
4222 Weak Infeed is BLOCKED (Weak
Inf. BLOCK)
Weak Infeed OUT ON
OFF
ON
OFF
* LED BO 25 22 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
