A Appendix
666
7SD5 Manual
C53000-G1176-C169-1
4289 High Speed/SOTF-O/C TRIP -
Only L1 (HS/SOF TRIP1pL1)
SOTF Overcurr. OUT * ON * LED BO 25 89 2 Yes
4290 High Speed/SOTF-O/C TRIP -
Only L2 (HS/SOF TRIP1pL2)
SOTF Overcurr. OUT * ON * LED BO 25 90 2 Yes
4291 High Speed/SOTF-O/C TRIP -
Only L3 (HS/SOF TRIP1pL3)
SOTF Overcurr. OUT * ON * LED BO 25 91 2 Yes
4292 High Speed/SOTF-O/C TRIP
1pole (HS/SOF TRIP 1p)
SOTF Overcurr. OUT * ON * LED BO 25 94 2 No
4293 High Speed/SOTF-O/C General
TRIP (HS/SOF Gen.TRIP)
SOTF Overcurr. OUT * ON * LED BO
4294 High Speed/SOTF-O/C TRIP
3pole (HS/SOF TRIP 3p)
SOTF Overcurr. OUT * ON * LED BO
4295 High Speed/SOTF-O/C TRIP
command L123 (HS/SOF
TRIPL123)
SOTF Overcurr. OUT * ON * LED BO 25 95 2 Yes
4403 >BLOCK Direct Transfer Trip
function (>BLOCK DTT)
DTT Direct Trip SP * * * LED BI BO
4412 >Direct Transfer Trip INPUT
Phase L1 (>DTT Trip L1)
DTT Direct Trip SP ON
OFF
**LEDBIBO
4413 >Direct Transfer Trip INPUT
Phase L2 (>DTT Trip L2)
DTT Direct Trip SP ON
OFF
**LEDBIBO
4414 >Direct Transfer Trip INPUT
Phase L3 (>DTT Trip L3)
DTT Direct Trip SP ON
OFF
**LEDBIBO
4417 >Direct Transfer Trip INPUT 3ph
L123 (>DTT Trip L123)
DTT Direct Trip SP ON
OFF
**LEDBIBO
4421 Direct Transfer Trip is switched
OFF (DTT OFF)
DTT Direct Trip OUT ON
OFF
**LEDBO51211Yes
4422 Direct Transfer Trip is BLOCKED
(DTT BLOCK)
DTT Direct Trip OUT ON
OFF
ON
OFF
* LED BO 51 22 1 Yes
4432 DTT TRIP command - Only L1
(DTT TRIP 1p. L1)
DTT Direct Trip OUT * ON * LED BO 51 32 2 No
4433 DTT TRIP command - Only L2
(DTT TRIP 1p. L2)
DTT Direct Trip OUT * ON * LED BO 51 33 2 No
4434 DTT TRIP command - Only L3
(DTT TRIP 1p. L3)
DTT Direct Trip OUT * ON * LED BO 51 34 2 No
4435 DTT TRIP command L123 (DTT
TRIP L123)
DTT Direct Trip OUT * ON * LED BO 51 35 2 No
5203 >BLOCK frequency protection
(>BLOCK Freq.)
Frequency Prot. SP ON
OFF
* * LED BI BO 70 176 1 Yes
5206 >BLOCK frequency protection
stage f1 (>BLOCK f1)
Frequency Prot. SP ON
OFF
* * LED BI BO 70 177 1 Yes
5207 >BLOCK frequency protection
stage f2 (>BLOCK f2)
Frequency Prot. SP ON
OFF
* * LED BI BO 70 178 1 Yes
5208 >BLOCK frequency protection
stage f3 (>BLOCK f3)
Frequency Prot. SP ON
OFF
* * LED BI BO 70 179 1 Yes
5209 >BLOCK frequency protection
stage f4 (>BLOCK f4)
Frequency Prot. SP ON
OFF
* * LED BI BO 70 180 1 Yes
5211 Frequency protection is switched
OFF (Freq. OFF)
Frequency Prot. OUT ON
OFF
* * LED BO 70 181 1 Yes
5212 Frequency protection is
BLOCKED (Freq. BLOCKED)
Frequency Prot. OUT ON
OFF
ON
OFF
* LED BO 70 182 1 Yes
5213 Frequency protection is ACTIVE
(Freq. ACTIVE)
Frequency Prot. OUT ON
OFF
* * LED BO 70 183 1 Yes
5232 Frequency protection: f1 picked
up (f1 picked up)
Frequency Prot. OUT * ON
OFF
* LED BO 70 230 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
