A.10 Measured Values
675
7SD5 Manual
C53000-G1176-C169-1
801 Temperat. rise for warning and trip (Θ/Θtrip
=)
Measurement - - - - - CFC CD DD
802 Temperature rise for phase L1 (Θ/ΘtripL1=) Measurement - - - - - CFC CD DD
803 Temperature rise for phase L2 (Θ/ΘtripL2=) Measurement - - - - - CFC CD DD
804 Temperature rise for phase L3 (Θ/ΘtripL3=) Measurement - - - - - CFC CD DD
833 I1 (positive sequence) Demand (I1dmd =) Demand meter - - - - - CFC CD DD
834 Active Power Demand (Pdmd =) Demand meter - - - - - CFC CD DD
835 Reactive Power Demand (Qdmd =) Demand meter - - - - - CFC CD DD
836 Apparent Power Demand (Sdmd =) Demand meter - - - - - CFC CD DD
837 I L1 Demand Minimum (IL1d Min) Min/Max meter - - - - - CFC CD DD
838 I L1 Demand Maximum (IL1d Max) Min/Max meter - - - - - CFC CD DD
839 I L2 Demand Minimum (IL2d Min) Min/Max meter - - - - - CFC CD DD
840 I L2 Demand Maximum (IL2d Max) Min/Max meter - - - - - CFC CD DD
841 I L3 Demand Minimum (IL3d Min) Min/Max meter - - - - - CFC CD DD
842 I L3 Demand Maximum (IL3d Max) Min/Max meter - - - - - CFC CD DD
843 I1 (positive sequence) Demand Minimum
(I1dmdMin)
Min/Max meter - - - - - CFC CD DD
844 I1 (positive sequence) Demand Maximum
(I1dmdMax)
Min/Max meter - - - - - CFC CD DD
845 Active Power Demand Minimum (PdMin=) Min/Max meter - - - - - CFC CD DD
846 Active Power Demand Maximum (PdMax=) Min/Max meter - - - - - CFC CD DD
847 Reactive Power Demand Minimum (QdMin=) Min/Max meter - - - - - CFC CD DD
848 Reactive Power Demand Maximum (Qd-
Max=)
Min/Max meter - - - - - CFC CD DD
849 Apparent Power Demand Minimum (SdMin=) Min/Max meter - - - - - CFC CD DD
850 Apparent Power Demand Maximum (Sd-
Max=)
Min/Max meter - - - - - CFC CD DD
851 I L1 Minimum (IL1Min=) Min/Max meter - - - - - CFC CD DD
852 I L1 Maximum (IL1Max=) Min/Max meter - - - - - CFC CD DD
853 I L2 Mimimum (IL2Min=) Min/Max meter - - - - - CFC CD DD
854 I L2 Maximum (IL2Max=) Min/Max meter - - - - - CFC CD DD
855 I L3 Minimum (IL3Min=) Min/Max meter - - - - - CFC CD DD
856 I L3 Maximum (IL3Max=) Min/Max meter - - - - - CFC CD DD
857 Positive Sequence Minimum (I1 Min=) Min/Max meter - - - - - CFC CD DD
858 Positive Sequence Maximum (I1 Max=) Min/Max meter - - - - - CFC CD DD
859 U L1E Minimum (UL1EMin=) Min/Max meter - - - - - CFC CD DD
860 U L1E Maximum (UL1EMax=) Min/Max meter - - - - - CFC CD DD
861 U L2E Minimum (UL2EMin=) Min/Max meter - - - - - CFC CD DD
862 U L2E Maximum (UL2EMax=) Min/Max meter - - - - - CFC CD DD
863 U L3E Minimum (UL3EMin=) Min/Max meter - - - - - CFC CD DD
864 U L3E Maximum (UL3EMax=) Min/Max meter - - - - - CFC CD DD
865 U L12 Minimum (UL12Min=) Min/Max meter - - - - - CFC CD DD
867 U L12 Maximum (UL12Max=) Min/Max meter - - - - - CFC CD DD
868 U L23 Minimum (UL23Min=) Min/Max meter - - - - - CFC CD DD
869 U L23 Maximum (UL23Max=) Min/Max meter - - - - - CFC CD DD
870 U L31 Minimum (UL31Min=) Min/Max meter - - - - - CFC CD DD
871 U L31 Maximum (UL31Min=) Min/Max meter - - - - - CFC CD DD
874 U1 (positive sequence) Voltage Minimum (U1
Min =)
Min/Max meter - - - - - CFC CD DD
875 U1 (positive sequence) Voltage Maximum
(U1 Max =)
Min/Max meter - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
