Siemens SIPROTEC 7UT633*-* N series User Manual

A Appendix
550
7UT613/63x Manual
C53000-G1176-C160-2
134 DMT/IDMT 3I0 2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT 3I0 2
136 DMT/IDMT 3I0 3 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT 3I0 3
138 DMT/IDMT Earth2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Earth 2
140 UNBALANCE LOAD Disabled
Definite Time
TOC IEC
TOC ANSI
DT/thermal
Disabled Unbalance Load (Negative Se-
quence)
142 THERM. OVERLOAD Disabled
th rep w.o. sen
th repl w. sens
IEC354
Disabled Thermal Overload Protection
143 OVEREXC. PROT. Disabled
Enabled
Disabled Overexcitation Protection (U/f)
144 THERM.OVERLOAD2 Disabled
th rep w.o. sen
th repl w. sens
IEC354
Disabled Thermal Overload Protection 2
150 REVERSE POWER Disabled
Enabled
Disabled Reverse Power Protection
151 FORWARD POWER Disabled
Enabled
Disabled Forward Power Supervision
152 UNDERVOLTAGE Disabled
Enabled
Disabled Undervoltage Protection
153 OVERVOLTAGE Disabled
Enabled
Disabled Overvoltage Protection
156 FREQUENCY Prot. Disabled
Enabled
Disabled Over / Underfrequency Protection
170 BREAKER FAILURE Disabled
Enabled
Disabled Breaker Failure Protection
171 BREAKER FAIL. 2 Disabled
Enabled
Disabled Breaker Failure Protection 2
180 DISCON.MEAS.LOC Disabled
Enabled
Disabled Disconnect measurment location
181 M.V. SUPERV Disabled
Enabled
Enabled Measured Values Supervision
182 Trip Cir. Sup. Disabled
2 Binary Inputs
1 Binary Input
Disabled Trip Circuit Supervision
Addr. Parameter Setting Options Default Setting Comments

Siemens SIPROTEC 7UT633*-* N series Specifications

General

Brand	Siemens
Model	SIPROTEC 7UT633*-* N series
Category	Protection Device
Language	English
