Siemens SIPROTEC 7UT633*-* N series User Manual

A.7 Functional Scope
549
7UT613/63x Manual
C53000-G1176-C160-2
A.7 Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
105 PROT. OBJECT 3 phase transf.
1 phase transf.
Autotransf.
Autotr. node
Generator/Motor
3ph Busbar
1ph Busbar
3 phase transf. Protection Object
112 DIFF. PROT. Disabled
Enabled
Enabled Differential Protection
113 REF PROT. Disabled
Enabled
Disabled Restricted earth fault protection
114 REF PROT. 2 Disabled
Enabled
Disabled Restricted earth fault protection 2
117 COLDLOAD PICKUP Disabled
Enabled
Disabled Cold Load Pickup
120 DMT/IDMT Phase Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Phase
122 DMT/IDMT 3I0 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT 3I0
124 DMT/IDMT Earth Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Earth
127 DMT 1PHASE Disabled
Enabled
Disabled DMT 1Phase
130 DMT/IDMT Phase2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Phase 2
132 DMT/IDMT Phase3 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Phase 3
