Siemens SIPROTEC 7UT633*-* N series User Manual

A.8 Settings
553
7UT613/63x Manual
C53000-G1176-C160-2
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold I meas. loca-
tion 1
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold I meas. loca-
tion 2
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold I meas. loca-
tion 3
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold I meas. loca-
tion 4
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold I meas. loca-
tion 5
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I1
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I2
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I3
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I4
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I5
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I6
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I7
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I8
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I9
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I10
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I11
0 Pick-up thresh. Flx 1A
5A
0.1A
0.05 .. 35.00 A
0.25 .. 175.00 A
0.005 .. 3.500 A
2.00 A
10.00 A
0.200 A
Pick-up threshold I12
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold IZ1
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold IZ2
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold IZ3
0 Pick-up thresh. Flx 1A
5A
0.05 .. 35.00 A
0.25 .. 175.00 A
2.00 A
10.00 A
Pick-up threshold IZ4
0 Pick-up thresh. Flx 0.001 .. 1.500 A 0.100 A Pick-up threshold IZ3 sens.
0 Pick-up thresh. Flx 0.001 .. 1.500 A 0.100 A Pick-up threshold IZ4 sens.
0 Pick-up thresh. Flx 0.05 .. 35.00 I/InS 2.00 I/InS Pick-up threshold I-side
0 P.U. THRESHOLD Flx 1.0 .. 170.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD Flx 1.0 .. 170.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD Flx 40.00 .. 66.00 Hz 51.00 Hz Pickup Threshold
0 P.U. THRESHOLD Flx 10.00 .. 22.00 Hz 18.00 Hz Pickup Threshold
0 P.U. THRESHOLD Flx 1A
5A
1.7 .. 3000.0 W
8.5 .. 15000.0 W
200.0 W
1000.0 W
Pickup Threshold
0 Pick-up thresh. Flx 0.01 .. 17.00 P/SnS 1.10 P/SnS Pick-up threshold P-side
0 Pick-up thresh. Flx 1A
5A
1.7 .. 3000.0 VAR
8.5 .. 15000.0 VAR
200.0 VAR
1000.0 VAR
Pick-up threshold Q meas. loca-
tion
Addr. Parameter Function C Setting Options Default Setting Comments
