Siemens SIPROTEC User Manual

Functions
2.7 Teleprotection for Distance Protection (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
216
4055 Dis.T.Carr.Fail OUT Dis. Telep. Carrier CHANNEL FAILURE
4056 Dis.T.SEND OUT Dis. Telep. Carrier SEND signal
4057 Dis.T.SEND L1 OUT Dis. Telep. Carrier SEND signal, L1
4058 Dis.T.SEND L2 OUT Dis. Telep. Carrier SEND signal, L2
4059 Dis.T.SEND L3 OUT Dis. Telep. Carrier SEND signal, L3
4060 DisJumpBlocking OUT Dis.Tele.Blocking: Send signal with jump
4068 Dis.T.Trans.Blk OUT Dis. Telep. Transient Blocking
4070 Dis.T.BL STOP OUT Dis. Tele.Blocking: carrier STOP signal
4080 Dis.T.UB Fail1 OUT Dis. Tele.Unblocking: FAILURE Channel 1
4081 Dis.T.UB Fail2 OUT Dis. Tele.Unblocking: FAILURE Channel 2
4082 Dis.T.BL STOPL1 OUT DisTel Blocking: carrier STOP signal, L1
4083 Dis.T.BL STOPL2 OUT DisTel Blocking: carrier STOP signal, L2
4084 Dis.T.BL STOPL3 OUT DisTel Blocking: carrier STOP signal, L3
No. Information Type of In-
formation
Comments
