Functions
2.15 Sensitive Earth Flt.(comp/ isol. starp.)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
301
2.15.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Additional Settings.
2.15.4 Information List
Addr. Parameter Setting Options Default Setting Comments
3001 Sens. Earth Flt Alarm Only
ON: with Trip
OFF
Alarm Only Sensitive Earth Flt.(comp/ isol.
starp.)
3002 3U0> 1 .. 150 V 50 V 3U0> pickup
3003 Uph-e min 10 .. 100 V 40 V Uph-e min of faulted phase
3004 Uph-e max 10 .. 100 V 75 V Uph-e max of healthy phases
3005 3I0> 0.003 .. 1.000 A 0.050 A 3I0> Release directional element
3006 T Sens.E/F 0.00 .. 320.00 sec 1.00 sec Time delay for sens. E/F detection
3007 T 3U0> 0.00 .. 320.00 sec 0.00 sec Time delay for sens. E/F trip
3008A TRIP Direction Forward
Reverse
Non-Directional
Forward Direction for sens. E/F trip
3010 CT Err. I1 0.003 .. 1.600 A 0.050 A Current I1 for CT Angle Error
3011 CT Err. F1 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I1
3012 CT Err. I2 0.003 .. 1.600 A 1.000 A Current I2 for CT Angle Error
3013 CT Err. F2 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I2
No. Information Type of In-
formation
Comments
1219 3I0senA= VI Active 3I0sen (sensitive Ie) =
1220 3I0senR= VI Reactive 3I0sen (sensitive Ie) =
1251 >SensEF on SP >Switch on sensitive E/F detection
1252 >SensEF off SP >Switch off sensitive E/F detection
1253 >SensEF block SP >Block sensitive E/F detection
1260 SensEF on/offBI IntSP Sensitve E/F detection ON/OFF via BI
1261 SensEF OFF OUT Sensitve E/F detection is switched OFF
1262 SensEF BLOCK OUT Sensitve E/F detection is BLOCKED
1263 SensEF ACTIVE OUT Sensitve E/F detection is ACTIVE
1271 SensEF Pickup OUT Sensitve E/F detection picked up
1272 SensEF Phase L1 OUT Sensitve E/F detection Phase L1
1273 SensEF Phase L2 OUT Sensitve E/F detection Phase L2
1274 SensEF Phase L3 OUT Sensitve E/F detection Phase L3
1276 SensEF Forward OUT Sensitve E/F detection Forward
1277 SensEF Reverse OUT Sensitve E/F detection Reverse
1278 SensEF undefDir OUT Sensitve E/F detection Undef. Direction
1281 SensEF TRIP OUT Sensitve E/F detection TRIP command
1291 SensEF 3U0> OUT Sensitve E/F detection 3U0> pickup
