2.21 Fault Locator
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
395
2.21.4 Information List
No. Information Type of In-
formation
Comments
1111 FL active OUT Fault locator active
1114 Rpri = VI Flt Locator: primary RESISTANCE
1115 Xpri = VI Flt Locator: primary REACTANCE
1117 Rsec = VI Flt Locator: secondary RESISTANCE
1118 Xsec = VI Flt Locator: secondary REACTANCE
1119 dist = VI Flt Locator: Distance to fault
1120 d[%] = VI Flt Locator: Distance [%] to fault
1122 dist = VI Flt Locator: Distance to fault
1123 FL Loop L1E OUT_Ev Fault Locator Loop L1E
1124 FL Loop L2E OUT_Ev Fault Locator Loop L2E
1125 FL Loop L3E OUT_Ev Fault Locator Loop L3E
1126 FL Loop L1L2 OUT_Ev Fault Locator Loop L1L2
1127 FL Loop L2L3 OUT_Ev Fault Locator Loop L2L3
1128 FL Loop L3L1 OUT_Ev Fault Locator Loop L3L1
1131 RFpri= VI Flt Locator: primary FAULT RESISTANCE
1132 Flt.Loc.invalid OUT Fault location invalid
1133 Flt.Loc.ErrorK0 OUT Fault locator setting error K0,angle(K0)
1134 two ended FO OUT_Ev Two ended fault location
1143 BCD d[1%] OUT BCD Fault location [1%]
1144 BCD d[2%] OUT BCD Fault location [2%]
1145 BCD d[4%] OUT BCD Fault location [4%]
1146 BCD d[8%] OUT BCD Fault location [8%]
1147 BCD d[10%] OUT BCD Fault location [10%]
1148 BCD d[20%] OUT BCD Fault location [20%]
1149 BCD d[40%] OUT BCD Fault location [40%]
1150 BCD d[80%] OUT BCD Fault location [80%]
1151 BCD d[100%] OUT BCD Fault location [100%]
1152 BCD dist. VALID OUT BCD Fault location valid
