Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
517
3.1.2.4 Interface Modules
Replacing interface modules
The interface modules are located on the processor board C-CPU-1 (No. 1 in Figure 3-3 and 3-4).
Figure 3-10 Processor board C-CPU-1 with interface modules (maximum configuration)
Note
Surface-mounted devices with fibre optics connection have their fibre optics module fitted in the inclined
housing on the case bottom. The CPU module, however, has an RS232 interface module which communicates
electrically with the fibre optics module in the inclined housing.
