Functions
2.9 Teleprotection for Earth Fault Protection (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
264
2.9.9 Information List
No. Information Type of In-
formation
Comments
1311 >EF Teleprot.ON SP >E/F Teleprotection ON
1312 >EF TeleprotOFF SP >E/F Teleprotection OFF
1313 >EF TeleprotBLK SP >E/F Teleprotection BLOCK
1318 >EF Rec.Ch1 SP >E/F Carrier RECEPTION, Channel 1
1319 >EF Rec.Ch2 SP >E/F Carrier RECEPTION, Channel 2
1320 >EF UB ub 1 SP >E/F Unblocking: UNBLOCK, Channel 1
1321 >EF UB bl 1 SP >E/F Unblocking: BLOCK, Channel 1
1322 >EF UB ub 2 SP >E/F Unblocking: UNBLOCK, Channel 2
1323 >EF UB bl 2 SP >E/F Unblocking: BLOCK, Channel 2
1324 >EF BlkEcho SP >E/F BLOCK Echo Signal
1325 >EF Rec.Ch1 L1 SP >E/F Carrier RECEPTION, Channel 1, Ph.L1
1326 >EF Rec.Ch1 L2 SP >E/F Carrier RECEPTION, Channel 1, Ph.L2
1327 >EF Rec.Ch1 L3 SP >E/F Carrier RECEPTION, Channel 1, Ph.L3
1328 >EF UB ub 1-L1 SP >E/F Unblocking: UNBLOCK Chan. 1, Ph.L1
1329 >EF UB ub 1-L2 SP >E/F Unblocking: UNBLOCK Chan. 1, Ph.L2
1330 >EF UB ub 1-L3 SP >E/F Unblocking: UNBLOCK Chan. 1, Ph.L3
1371 EF Tele SEND L1 OUT E/F Telep. Carrier SEND signal, Phase L1
1372 EF Tele SEND L2 OUT E/F Telep. Carrier SEND signal, Phase L2
1373 EF Tele SEND L3 OUT E/F Telep. Carrier SEND signal, Phase L3
1374 EF Tele STOP L1 OUT E/F Telep. Block: carrier STOP signal L1
1375 EF Tele STOP L2 OUT E/F Telep. Block: carrier STOP signal L2
1376 EF Tele STOP L3 OUT E/F Telep. Block: carrier STOP signal L3
1380 EF TeleON/offBI IntSP E/F Teleprot. ON/OFF via BI
1381 EF Telep. OFF OUT E/F Teleprotection is switched OFF
1384 EF Tele SEND OUT E/F Telep. Carrier SEND signal
1386 EF TeleTransBlk OUT E/F Telep. Transient Blocking
1387 EF TeleUB Fail1 OUT E/F Telep. Unblocking: FAILURE Channel 1
1388 EF TeleUB Fail2 OUT E/F Telep. Unblocking: FAILURE Channel 2
1389 EF Tele BL STOP OUT E/F Telep. Blocking: carrier STOP signal
1390 EF Tele BL Jump OUT E/F Tele.Blocking: Send signal with jump
