2.19 Undervoltage and Overvoltage Protection (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
380
10319 Uph-e< PU L2 OUT Uph-e< Pickup L2
10320 Uph-e< PU L3 OUT Uph-e< Pickup L3
10321 Uph-e<< PU L1 OUT Uph-e<< Pickup L1
10322 Uph-e<< PU L2 OUT Uph-e<< Pickup L2
10323 Uph-e<< PU L3 OUT Uph-e<< Pickup L3
10325 Uph-ph< Pickup OUT Uph-ph< Pickup
10326 Uph-ph<< Pickup OUT Uph-ph<< Pickup
10327 Uphph<(<)PU L12 OUT Uphph<(<) Pickup L1-L2
10328 Uphph<(<)PU L23 OUT Uphph<(<) Pickup L2-L3
10329 Uphph<(<)PU L31 OUT Uphph<(<) Pickup L3-L1
10330 Uphph< TimeOut OUT Uphph< TimeOut
10331 Uphph<< TimeOut OUT Uphph<< TimeOut
10332 Uphph<(<) TRIP OUT Uphph<(<) TRIP command
10333 Uphph< PU L12 OUT Uph-ph< Pickup L1-L2
10334 Uphph< PU L23 OUT Uph-ph< Pickup L2-L3
10335 Uphph< PU L31 OUT Uph-ph< Pickup L3-L1
10336 Uphph<< PU L12 OUT Uph-ph<< Pickup L1-L2
10337 Uphph<< PU L23 OUT Uph-ph<< Pickup L2-L3
10338 Uphph<< PU L31 OUT Uph-ph<< Pickup L3-L1
No. Information Type of In-
formation
Comments
