Functions
2.21 Fault Locator
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
393
Table 2-16 Additional line section parameters
Addr. Setting Title C Setting Options Default Settings Description
6001 S1: Line angle A1: Line impedance angle
6002 S1: x' 1 A A1: Line reactance per unit
length: x' in Ω/km
5 A 0.0050-9.5000 Ω/km; without 0 0.1500 Ω/km
1 A A1: Line reactance per unit
length: x' in Ω/mile
5 A 0.0050-15.0000 Ω/mile;
without 0
0.2420 Ω/mile
6003 S1: c' 1 A A1: Capacitance per unit
length C' in μF/km
5 A 0.000-100.000 µF/km; 0 0.010 µF/km
1 A A1: Capacitance per unit
length C' in μF/mile
5 A 0.000-160.000 µF/mile; 0 0.016 µF/mile
6004 S1: Line length A1: Line length in kilometers
A1: Line length in miles
6008 S1: center ph. unknown/sym.
Phase 1
Phase 2
Phase 3
A1: Central phase
6021 S2: Line angle A2: Line impedance angle
6022 S2: x' 1 A A2: Line reactance per unit
length: x' in Ω/km
5 A 0.0050-9.5000 Ω/km; without 0 0.1500 Ω/km
1 A A2: Line reactance per unit
length: x' in Ω/mile
5 A 0.0050-15.0000 Ω/mile;
without 0
0.2420 Ω/mile
6023 S2: c' 1 A A2: Capacitance per unit
length C' in μF/km
5 A 0.000-100.000 µF/km; 0 0.010 µF/km
1 A A2: Capacitance per unit
length C' in μF/mile
5 A 0.000-160.000 µF/mile; 0 0.016 µF/mile
6024 S2: Line length A2: Line length in kilometers
A2: Line length in miles
6028 S2: center ph. unknown/sym.
Phase 1
Phase 2
Phase 3
A2: Central phase
6041 S3: Line angle A3: Line impedance angle
6042 S3: x' 1 A A3: Line reactance per unit
length: x' in Ω/km
5 A 0.0050-9.5000 Ω/km; without 0 0.1500 Ω/km
1 A A3: Line reactance per unit
length: x' in Ω/mile
5 A 0.0050-15.0000 Ω/mile;
without 0
0.2420 Ω/mile
6043 S3: c' 1 A A3: Capacitance per unit
length C' in μF/km
5 A 0.000-100.000 µF/km; 0 0.010 µF/km
1 A A3: Capacitance per unit
length C' in μF/mile
5 A 0.000-160.000 µF/mile; 0 0.016 µF/mile
6044 S3: Line length A3: Line length in kilometers
A3: Line length in miles
6048 S3: center ph. unknown/sym.
Phase 1
Phase 2
Phase 3
A3: Central phase
