Technical Data
4.1 General
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
578
DNP 3.0 FO
FO connector type ST connector transmitter/receiver
Connection for panel flush-mounting
housing
rear panel, slot „B“
Connection for surface-mounting housing Please use version with DNP3.0 RS485 in the
console housing at the housing bottom as well
as a separate electrical/optical converter
Transmission rate up to 19 200 baud
optical wavelength λ = 820 nm
Laser Class 1 according to EN60825-1/-2 when using glass fibre 50 μm / 125 µm or
when using glass fibre 62.5 μm / 125 µm
Permissible optical signal attenuation max. 8 dB, with glass fibre 62.5 μm / 125 µm
Transmission distance max. 1.5 km
Ethernet electrical (EN 100)
for IEC 61850 and DIGSI
Connection for panel flush-mounting
housing
rear panel, slot „B“
2 x RJ45 female connector
100BaseT acc. to IEEE802.3
Connection for surface-mounting housing at the bottom side of the console housing
Test voltage (regarding connector) 500 V; 50 Hz
Transmission rate 100 Mbit/s
Transmission distance 20 m
Ethernet optical (EN 100) for
IEC 61850 and DIGSI
FO connector type ST connector transmitter/receiver
Connection for panel flush-mounting
housing
rear panel, slot "B"
for surface-mounting housing not available
optical wavelength λ = 1350 nm
Transmission rate 100 Mbit/s
Laser class 1 acc. to
EN 60825-1/-2
when using glass fibre 50 μm / 125 µm
or
when using glass fibre 62.5 μm / 125 µm
Permissible optical signal attenuation max. 5 dB, with glass fibre 62.5 μm / 125 µm
Transmission distance max. 800 m
The OLM converter requires an operating voltage of DC 24 V. If the operating voltage is > DC 24 V, the additional power
supply 7XV5810-0BA00 is required.
