Siemens SIPROTEC User Manual

Technical Data
4.1 General
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
580
EMC Tests for Immunity (type tests)
Standards: IEC 60255-6 and -22, (product standards)
EN 61000-6-2 (generic standard) VDE 0435 part 301DIN VDE
0435-110
VDE 0435 part 301 DIN VDE 0435-110
High-frequency test
IEC 60255-22-1, Class III
and VDE 0435 Section 303, Class III
2,5kV (peak); 1MHz; τ = 15 µs; 400 surges per s; test duration
2s; R
i
= 200 Ω
Electrostatic Discharge
IEC 60255-22-2, Class IV
and IEC 61000-4-2, Class IV
8 kV contact discharge; 15 kV air discharge, both polarities;
150 pF; R
i
= 330 Ω
Irradiation with HF field, frequency sweep
IEC 60255-22-3, Class III
IEC 61000-4-3, Class III
IEEE Std C37.90.2-2004
10 V/m and 20 V/m; 80 MHz to 1000 MHz; 80 % AM; 1 kHz
10 V/m; 800 MHz to 960 MHz; 80 % AM; 1 kHz
20 V/m; 1,4 GHz to 2,0 GHz; 80 % AM; 1 kHz
Irradiation with HF field, single frequencies
IEC 60255-22-3, IEC 61000-4-3, Class III,
IEEE Std C37.90.2
– amplitude modulated
– pulse modulated
20 V/m; 80 MHz; 160 MHz; 450 MHz; 900 MHz; 80 % AM;
1kHz;
duty cycle > 10 s
35 V/m; 900 MHz; 50 % PM, repetition frequency 200 Hz
Fast transient disturbances/
Burst IEC 60255-22-4 and IEC 61000-4-4, Class IV
4 kV; 5 ns/50 ns; 5 kHz; burst length = 15 ms; repetition rate
300 ms; both polarities; R
i
= 50 Ω; test duration 1 min.
High energy surge voltages (SURGE),
IEC 61000-4-5 installation Class 3
- Auxiliary voltage
- Analog measuring inputs, binary inputs, relay outputs
Impulse: 1.2 µs / 50 µs
Common mode: 2 kV; 12 Ω; 9 µF
Diff. mode: 1 kV; 2 Ω; 18 µF
Common mode: 2 kV; 42 Ω; 0,5 µF
Diff. mode: 1 kV; 42 Ω; 0,5 µF
Line conducted HF, amplitude modulated
IEC 61000-4-6, Class III
10 V; 150 kHz to 80 MHz; 80 % AM; 1 kHz
Power system frequency magnetic field
IEC 60255-6
IEC 61000-4-8, Class IV
0,5 mT; 50 Hz,
30 A/m continuous; 300 A/m for 3 s; 50 Hz
Oscillatory Surge Withstand Capability
IEEE Std C37.90.1
2,5kV (peak); 1MHz; τ = 15 µs; 400 surges per s; test duration
2s; R
i
= 200 Ω
Fast Transient Surge Withstand Cap.
IEEE Std C37.90.1
4 kV; 5 ns/50 ns; 5 kHz; burst length = 15 ms; repetition rate 300
ms; both polarities: R
i
= 50 Ω; test duration 1 min.
Radiated Electromagnetic Interference
IEEE Std C37.90.2-2004
35 V/m; 80 MHz to 1000 MHz; Keying test
Damped oscillations IEC 60694, IEC 61000-4-18 2,5 kV (peak value), polarity alternating 100 kHz, 1 MHz, R
i
=
200 Ω
