Technical Data
4.26 Additional Functions
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
635
Operational Indication Buffer
Fault Logging
Fault Recording
Statistics (serial protection data interface)
Switching Statistics
Long-term mean values I
L1
dmd; I
L2
dmd; I
L3
dmd; I
1
dmd;
Pdmd; Pdmd Forw, Pdmd Rev;
Qdmd; QdmdForw; QdmdRev;
Sdmd
in primary values
Minimum and maximum values I
L1
; I
L2
; I
L3
; I
1
; I
L1
d; I
L2
d; I
L3
d; I
1
d;
U
L1-E
; U
L2-E
; U
L3-E
; U
1
;
U
L1-L2
; U
L2-L3
; U
L3-L1
; 3U
0
;
P Forw; P Rev; Q Forw; Q Rev; S; Pd; Qd; Sd;
cos ϕ Pos; cos ϕ Neg; f
in primary values
Remote measured values for currents I
L1
; I
L2
; I
L3
of remote end in % of I
NOperation
ϕ(I
L1
); ϕ(I
L2
); ϕ(I
L3
) (remote versus local) in °
Remote measured values for voltages U
L1
; U
L2
; U
L3
of remote end in % of U
NOperation
/√3
ϕ(U
L1
); ϕ(U
L2
); ϕ(U
L3
) (remote versus local) in °
Capacity 200 records
Capacity 8 faults with a total of max. 600 messages and up to 100 binary
signal traces (marks)
Number of stored fault records Max. 8
Storage time Max. 5 s for each fault
Approx. 15 s in total
Sampling rate at f
N
= 50 Hz 1 ms
Sampling rate at f
N
= 60 Hz 0.83 ms
Availability of transmission for applications with protec-
tion data interface
Availability in %/min and %/h
Delay time of transmission Resolution 0.01 ms
Number of trip events caused by the device Separately for each breaker pole (if single-pole tripping is possi-
ble)
Number of automatic reclosures
initiated by the device
Separate for 1-pole and 3-pole AR;
Separately for 1st AR cycle
and for all further cyles
Total of interrupted currents Pole segregated
Maximum interrupted current Pole segregated
