1632 R(Z4) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω R(Z4), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 2.400 Ω
1633 X(Z4) Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω X(Z4), Reactance
5A 0.010 .. 120.000 Ω 2.400 Ω
1634 RE(Z4) Ø-E Dis. Quadril. 1A 0.050 .. 250.000 Ω 12.000 Ω RE(Z4), Resistance for ph-e
faults
5A 0.010 .. 50.000 Ω 2.400 Ω
1635 T4 DELAY Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.90 sec T4 delay
1641 Op. mode Z5 Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode Z5
1642 R(Z5) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω R(Z5), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 2.400 Ω
1643 X(Z5)+ Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω X(Z5)+, Reactance for Forward
direction
5A 0.010 .. 120.000 Ω 2.400 Ω
1644 RE(Z5) Ø-E Dis. Quadril. 1A 0.050 .. 600.000 Ω 12.000 Ω RE(Z5), Resistance for ph-e
faults
5A 0.010 .. 120.000 Ω 2.400 Ω
1645 T5 DELAY Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.90 sec T5 delay
1646 X(Z5)- Dis. Quadril. 1A 0.050 .. 600.000 Ω 4.000 Ω X(Z5)-, Reactance for Reverse
direction
5A 0.010 .. 120.000 Ω 0.800 Ω
1651 Op. mode Z1B Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Forward Operating mode Z1B (overrreach
zone)
1652 R(Z1B) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 1.500 Ω R(Z1B), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 0.300 Ω
1653 X(Z1B) Dis. Quadril. 1A 0.050 .. 600.000
Ω 3.000 Ω X(Z1B), Reactance
5A 0.010 .. 120.000 Ω 0.600 Ω
1654 RE(Z1B) Ø-E Dis. Quadril. 1A 0.050 .. 600.000 Ω 3.000 Ω RE(Z1B), Resistance for ph-e
faults
5A 0.010 .. 120.000 Ω 0.600 Ω
1655 T1B-1phase Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.00 sec T1B-1phase, delay for single ph.
faults
1656 T1B-multi-phase Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 0.00 sec T1B-multi-ph, delay for multi ph.
faults
1657 1st AR -> Z1B Dis. General
Dis. Quadril.
Dis. MHO
NO
YES
NO Z1B enabled before 1st AR (int.
or ext.)
1661 Op. mode Z6 Dis. Quadril. Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode Z6
1662 R(Z6) Ø-Ø Dis. Quadril. 1A 0.050 .. 600.000 Ω 15.000 Ω R(Z6), Resistance for ph-ph-
faults
5A 0.010 .. 120.000 Ω 3.000 Ω
1663 X(Z6)+ Dis. Quadril. 1A 0.050 .. 600.000 Ω 15.000 Ω X(Z6)+, Reactance for Forward
direction
5A 0.010 .. 120.000 Ω 3.000 Ω
1664 RE(Z6) Ø-E Dis. Quadril. 1A 0.050 .. 600.000 Ω 15.000 Ω RE(Z6), Resistance for ph-e
faults
5A 0.010 .. 120.000 Ω 3.000 Ω
1665 T6 DELAY Dis. General
Dis. Quadril.
Dis. MHO
0.00 .. 30.00 sec; ∞ 1.50 sec T6 delay
1666 X(Z6)- Dis. Quadril. 1A 0.050 .. 600.000 Ω 4.000 Ω X(Z6)-, Reactance for Reverse
direction
5A 0.010 .. 120.000 Ω 0.800 Ω
1701 Op. mode Z1 Dis. MHO Forward
Reverse
Inactive
Forward Operating mode Z1
Addr. Parameter Function C Setting Options Default Setting Comments
