Siemens SIPROTEC User Manual

Functions
2.1 General
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
71
6028 S2: center ph. unknown/sym.
Phase 1
Phase 2
Phase 3
unknown/sym. S2: center phase
6029 S2: XE/XL -0.33 .. 10.00 1.00 S2: Zero seq. compensat-
ing factor XE/XL
6030 S2: RE/RL -0.33 .. 10.00 1.00 S2: Zero seq. compensat-
ing factor RE/RL
6031 S2: K0 0.000 .. 4.000 1.000 S2: Zero seq. compensat-
ing factor K0
6032 S2: angle K0 -180.00 .. 180.00 ° 0.00 ° S2: Zero seq. compensat-
ing angle of K0
6041 S3: Line angle 30 .. 89 ° 85 ° S3: Line angle
6042 S3: x' 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S3: feeder reactance per
km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
6042 S3: x' 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S3: feeder reactance per
mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6043 S3: c' 1A 0.000 .. 100.000 µF/km 0.010 µF/km S3: feeder capacitance c'
in µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
6043 S3: c' 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi S3: feeder capacitance c'
in µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
6044 S3: Line length 0.1 .. 1000.0 km 100.0 km S3: Line length in kilome-
ter
6044 S3: line length 0.1 .. 650.0 Miles 62.1 Miles S3: line length in miles
6048 S3: center ph. unknown/sym.
Phase 1
Phase 2
Phase 3
unknown/sym. S3: center phase
6049 S3: XE/XL -0.33 .. 10.00 1.00 S3: Zero seq. compensat-
ing factor XE/XL
6050 S3: RE/RL -0.33 .. 10.00 1.00 S3: Zero seq. compensat-
ing factor RE/RL
6051 S3: K0 0.000 .. 4.000 1.000 S3: Zero seq. compensat-
ing factor K0
6052 S3: angle K0 -180.00 .. 180.00 ° 0.00 ° S3: Zero seq. compensat-
ing angle of K0
