Siemens SLD4 - Advanced Configuration Setting; Bus Detection Threshold Setting Process

Bus Detection
Loop Detector Application Notes SLD4
667/HQ/45200/101
12
3.3. Advanced Configuration Setting
The following are suggested settings applicable for detecting buses with the SLD4 Loop De-
tector;
Suggested Bus Detection Settings
Setting
Value
Comment
Switch Config
Disable
This will allow for specific
thresholds to be set.
Loop Mode
Hz
Table 5 : Suggested Bus Detection Settings
3.3.1. Bus Detection Threshold Setting Process
1 Click on the Read button to load the current detector configuration into the tool for editing.
See Figure 1below.
Figure 2 : Reading the SLD4 Configuration
Read Button
