Siemens SQM5 Series Technical Instructions

SQM5… Reversing Actuators Technical Instructions
155-517P25
Rev. 1, July, 2000
Siemens Building Technologies, Inc. Page 11
AGA56.9… circuit boards.
See Figures 11 and 12.
1. Connect line voltage to terminal L. Terminal L must be powered at all times.
2. Connect neutral to terminal N.
3. Connect ground to the terminal located to the right of the auto/manual switch.
4. For applications where terminals Z, ZL and A are not used, bridge terminals L1 and
L. If terminals Z, A or ZL are used, terminal L1 must not be bridged with terminal L.
In addition, terminal L1 must never be powered simultaneously with terminals Z, A
or ZL. However, terminal L1 must be powered once terminals A, Z and ZL are no
longer powered and modulating operation is required (refer to application guide for
typical installation examples).
5. Connect the input and output control signal wires to the appropriate terminals.
ALZ
AGA56.9...
Y
0...3
25% 50% 75% MAXMIN
25%
50%
75%
MAX
MIN
POS
L1 P
POS
LIN
Y
0...3
ZL
Y
0...3
POS
N
2
1
J1
J2
2
REG
MAX
MIN
Y
0...3
MIN MAX
OPE
MAX
MIN
MAX
MIN
SHIFT
LIN
U1..3
1
MAN
AUTO
SW 2
SW1
(+2 V)
0...2 V
135 Ohm
ZF
4...20 mA
M
0...10 V
0...20 mA
4...20 mA
MU1U2U3
M
Y
0
Y
1
Y
2
Y
3
U 4
12313
11 21
M
I
II
III
IV V
ASZ...
(1000 Ohm)
12 22 13 23 14 1524 25
4
5
EA0557R2
51
N
II
III
I
IV...VIII
"economy"
minimum
maximum
auxilliary
Figure 11. Basic Functional Diagram of AGA56.9…
