Technical Instructions
Document No. 155-517P25
Rev. 1, July, 2000
Page 2 Siemens Building Technologies, Inc.
Features, Continued
• Connections for both base and face mounting
• Low hysteresis actuator and potentiometer gearing
• Externally visible position indication
• Selection of input and output signals
• Zero and span adjustment
• Field exchangeable circuit boards and potentiometers
• Electronic damper linearization function
• Split range and selectable parallel or master/slave operation
• Adjustable input signal override function
Table Of Contents
Application Page 3
Product Numbers
Product numbers for pre-assembled UL/CSA/CE-approved
actuators, Table 1 Page 3
Product numbers for accessories, Table 2 Page 4
SQM5… Product Number Identification Legend Page 5
Installation and Operating Instructions
Shaft Installation Page 6
Rotational Direction Verification Page 7
Actuator Mounting Page 7
Switch Adjustment Page 7
Shaft Adjustment Page 8
Cam Drum Adjustment Page 8
Wiring
Electrical Connection Page 8
Grounding Page 8
Wiring Connections
AGA56.1… circuit boards Page 8
AGA56.41/42/43… circuit boards Page 9
AGA56.9… circuit boards Page 11
Commissioning
Power Actuator Page 12
Modulation Adjustment Page 12
Zero Adjustment Page 12
Span Adjustment Page 12
Position Indicating Dial Adjustment Page 13
Cover Installation Page 13
Features
SQM5x.xxxxxZx actuators Page 14
SQM5x.xxxxxGx actuators Page 15
SQM5x.xxxxxHx actuators Page 15
SQM5x.xxxxxKx actuators Page 15
SQM5x.xxxxxAx actuators Page 16
Service Guide
Reversing Rotational Direction Page 16
Shaft Installation Page 17
Circuit Board Installation Page 17
AGA56.41/42/43… Page 18
AGA56.9A Page 19
AGA56.1A97 Page 21
Potentiometer Removal/Installation Page 22
Specification Data Page 23
Dimensions Page 26
