Siemens SQM5 Series Technical Instructions

Technical Instructions
Document No. 155-517P25
Rev. 1, July, 2000
Page 26 Siemens Building Technologies, Inc.
Dimensions
The first dimension given is measured in inches. Millimeters are shown in parentheses.
M 8
ALLOW 3.5" SPACE FOR 
COVER REMOVAL
1-3/16 
(30)
5/8 
(16)
2-5/8 
(67)
1/4 
(6)
1-3/16 
(30)
1-7/16 
(36)
EA0522R1
5-1/4 
(133)
7-1/16 
(180)
3/8 
(10)
Pg 13.5 / 1/2" 
NPSM
1/4"-20
UNC
7-1/16
(180)
5/16
(8.5)
6-7/16
(164)
5/16
(7.5)
1/16
(1)
1/8
(3.5)
EA0542R2
4-7/16
(113)
3-1/8
(80)
5-3/16
(132)
Figure 28. SQM5x.xxxRxx Dimensions.
