SQM5… Reversing Actuators Technical Instructions
155-517P25
Rev. 1, July, 2000
Siemens Building Technologies, Inc. Page 25
Specifications,
continued
AGA56.43A…
AGA56.9A
ASZ... Potentiometers
AGA56.43A… Electronic circuit boards Same specifications as AGA56.41A
except:
Input signal 0-10 Vdc
Impedance
Voltage input ≥100kΩ
AGA56.9A… Multi function electronic Single potentiometer
circuit boards ASZ... (1000 ohm) is required
Operating voltage 24 Vac +10%-15%
110 Vac -15% to 120 Vac +10%
220 Vac -15% to 240 Vac +10%
Operating frequency 50-60 Hz
Input signals 4-20 mA,
0-20 mA,
0-10 Vdc,
0-135 ohm
Impedance
Current input ≤300 Ω
Voltage input ≥100kΩ
Output signals 4-20 mA
0-20 mA,
0-10Vdc
Zero adjustment MIN: 0-75 %
Span adjustment MAX: min-100 %
Split ranging (SHIFT) 4-20 mA on terminal ZF
Input signal override (POS) Line voltage (... Vac) on terminal P
adjust with POS potentiometer
Ambient operating temperature -5 to 140°F (-20 to 60°C)
Shipping temperature -58 to 140°F (-50 to 60°C)
Auto/manual switch 2-position switch
Manual toggle switch 3-position switch
Weight 0.7 lb. (0.33 kg)
ASZ... Potentiometers
Versions Single and double potentiometer
Resistor values See
Table 2
and
data sheet 7921
.
Hysteresis < 0.3 % related to drive shaft
