Siemens SQM5 Series Technical Instructions

Technical Instructions
Document No. 155-517P25
Rev. 1, July, 2000
Page 4 Siemens Building Technologies, Inc.
Table 2. Product Numbers for Accessories.
Electronic circuit boards
AGA56.1A97 24-250 Vac (A) board for SQM5x.xxxxxAx
AGA56.9A87 24 Vac (Z) board for SQM5x.xxxxxZx
AGA56.9A17 120 Vac (Z) board for SQM5x.xxxxxZx
AGA56.9A27 220 Vac (Z) board for SQM5x.xxxxxZx
AGA56.41A87 24 Vac (G) board for SQM5x.xxxxxGx
AGA56.41A17 110 Vac (G) board for SQM5x.xxxxxGx
AGA56.41A27 220 Vac (G) board for SQM5x.xxxxxGx
AGA56.42A17 110 Vac (H) board for SQM5x.xxxxxHx
AGA56.42A27 220 Vac (H) board for SQM5x.xxxxxHx
AGA56.42A87 24 Vac (H) board for SQM5x.xxxxxHx
AGA56.43A17 110 Vac (K) board for SQM5x.xxxxxKx
AGA56.43A27 220 Vac (K) board for SQM5x.xxxxxKx
AGA56.43A87 24 Vac (K) board for SQM5x.xxxxxKx
See Product Number Identification Legend, Figure 1
.
Mounting Brackets & Adapters
AGA57.3 for replacement of Honeywell MOD III, IV
actuators
AGA57.4 for replacement of Honeywell M640/740/940 and
Barber Colman EA20/40/50/60 actuators. Directly
adaptable to Eclipse butterfly valves.
ASK33.9 mounting kit for direct attachment to Siemens
VKF41... butterfly valve. (Shaft AGA58.1 required)
Shafts
AGA58.1 10 mm round with key. Gear end only
AGA58.2 12 mm round with key. Gear end only
AGA58.3 9 mm square. Two ended
AGA58.4 3/8 inch square. Two ended
AGA58.7 14 mm round with key. Gear end only
For exact shaft sizes, refer to DIMENSIONS
.
Crank Arm, Push Rods
338 031 Crank arm kit. Includes two crank arms for
connecting the AGA58.4 shaft to a ∅ 1/2-inch damper
shaft with two ball joints. (does not include push rod)
338 041 ∅ 5/16" damper push rod, 12 inches long.
338 042 ∅ 5/16" damper push rod, 15 inches long.
338 043 ∅ 5/16" damper push rod, 18 inches long.
338 044 ∅ 5/16" damper push rod, 24 inches long.
338 045 ∅ 5/16" damper push rod, 36 inches long.
338 046 ∅ 5/16" damper push rod, 48 inches long.
Potentiometers
ASZ12.803 1000
Ω
, 90°
ASZ12.833 1000
Ω
, 135°
ASZ22.803 1000/1000
Ω
double potentiometer, 90°
ASZ22.833 1000/1000
Ω
double potentiometer, 135°
Additional potentiometer models available. See
Siemens technical data sheet 7921.
