TX-I/O Modules
TX-I/O Modules
TX-I/O Modules are modular expansion I/O consisting of an electronics module and a
terminal base; they receive power from a TX-I/O Power Supply or Bus Connection
Module.
 The electronics module performs A/D or D/A conversion, signal processing, point
monitoring, and command output.
 The terminal base provides for termination of field wiring and connection of the self-
forming TX-I/O island bus.
The design of the TX-I/O Modules provides optimum diagnostics and results in a more
efficient installation and maintenance workflow.
 Field wiring may be terminated prior to installation of electronics.
 Connected peripheral devices can be measured without affecting or being affected
by the I/O module.
 Hot-swappable electronic components allow powered electronics to be
disconnected and replaced without removing terminal wiring or disturbing the self-
forming bus.
