SIGMATEK C-DIAS Technical Data

C-DIAS ANALOG INPUT MODULE CAI 042
Page 16 02.08.2011
Registers used in Communication over the C-Dias bus
Register overview
Register Description Address
STATUSR Module status (error messages, operating status) 0x00
CMDR Instruction register (operating mode settings) 0x01
CFG Global configurations register 0x02
VER Firmware version 0x04 – 0x06
CFGR1 Configuration for channel 1 0x10
CFGR2 Configuration for channel 2 0x11
CFGR3 Configuration for channel 3 0x12
CFGR4 Configuration for channel 4 0x13
SR1 Error status for channel 1 0x18
SR2 Error status for channel 2 0x19
SR3 Error status for channel 3 0x1A
SR4 Error status for channel 4 0x1B
DATA1_P0_F1 Data for filter output 1 Channel1 Page 0 0x20 – 0x23
DATA1_P0_F2 Data for filter output 2 Channel1 Page 0 0x24 – 0x27
DATA2_P0_F1 Data for filter output 1 Channel2 Page 0 0x28 – 0x2B
DATA2_P0_F2 Data for filter output 2 Channel2 Page 0 0x2C – 0x2F
DATA3_P0_F1 Data for filter output 1 Channel3 Page 0 0x30 – 0x33
DATA3_P0_F2 Data for filter output 2 Channel3 Page 0 0x34 – 0x37
DATA4_P0_F1 Data for filter output 1 Channel4 Page 0 0x38 – 0x3B
DATA4_P0_F2 Data for filter output 2 Channel4 Page 0 0x3C – 0x3F
DATA1_P1_F1 Data for filter output 1 Channel1 Page 1 0x40 – 0x43
DATA1_P1_F2 Data for filter output 2 Channel1 Page 1 0x44 – 0x47
DATA2_P1_F1 Data for filter output 1 Channel2 Page 1 0x48 – 0x4B
DATA2_P1_F2 Data for filter output 2 Channel2 Page 1 0x4C – 0x4F
DATA3_P1_F1 Data for filter output 1 Channel3 Page 1 0x50 – 0x53
DATA3_P1_F2 Data for filter output 2 Channel3 Page 1 0x54 – 0x57
DATA4_P1_F1 Data for filter output 1 Channel4 Page 1 0x58 – 0x5B
DATA4_P1_F2 Data for filter output 2 Channel4 Page 1 0x5C – 0x5F
