SIGMATEK C-DIAS Technical Data

C-DIAS ANALOG INPUT MODULE CAI 042
02.08.2011 Page 19
VER –Version register
Bit 7 6 5 4 3 2 1 0
VER0 VER[7..0]
VER1 VER[15..8]
VER2 VER[23..16]
R/W R R R R R R R R
Version number of the Firmware:
• VER[7..0] Revision number (binary)
• VER[15..8] Subversion number (binary)
• VER[24..16] Main version number (binary)
Example:
VER2 VER1 VER0 Version
1 9 14 V01.09.14
Configuration register for Channel x – CFGRx
Bit 7 6 5 4 3 2 1 0
CFGRx EN - - - - - FIL1 FIL0
R/W
Initial Value 1 0 0 0 0 0 0 0
x...[1..4]
• BIT7-EN: Enable
The channel is active when this bit is set and inactive when cleared.
• BIT1-FIL1: Filter selection for filter 2
See filter table
• BIT0-FIL0: Filter selection for 2
See filter table
