SIGMATEK C-DIAS Technical Data

C-DIAS ANALOG INPUT MODULE CAI 042
LASAL EEProm Data
Calibration data CAI042 (24C02 is organized by byte):
Address Data Description
$00 $xx Check sum
$01 123 Identification
$02 5 Module group 5=CAI
$03 4 Module version 4=CAI042
$04 4 Number of channels
$05 10 Hardware version $10=HW 1.0
$06-$3F 0 FILL
$10 Serial number
AI calibration data
$40 $xxxx Check sum
$42 12345 Identification
$44 9 Length of the following data block in WORD
$46 4 Number of channels
$48-$57 „xxxxxx“ Serial number as 16-byte string. E.G.: „31333_01_0019___“
$58-$AF 0 FILL
$B0-$B3 xxx* Head1 (CalibrateCounter)
$B4-$B7 xxx* Head1 (ZeroLevel)
$B8-$BB xxx* Head1 (CalibrateLevel)
$BC-$BF xxx* Head1 (CalibrateWeight)
$C0-$C3 xxx* Head1 (MaxWeight)
$C4-$D7 xxx* Head2 (partitioned the same as Head1)
$D8-$EB xxx* Head3 (partitioned the same as Head1)
$EC-$FF xxx* Head4 (partitioned the same as Head1)
* Customer specific data (not require for the operating of the module).
