12.2. Device Error control system
Error Reports in conjunction with the control system.
Nr.
System error
Description
System reaction
E10
DEVICE_UNKNOWN_DEVICE
Description:
Device Type (14,4V, 18V) could not be detected
Possible cause:
• Wrong type of PCB (14,4 / 18V)
• Wrong Firmware. (The Firmware does not support this
tool type.
• Hardware failure when reading coding resistors
Rectification:
1. Try again, unplug and plug the battery
2. Replace PCB (Pos.198)
Stop
The tool is switched off.
E11
DEVICE_WRONG_BATTERY
Description:
Plugged Battery is known but not valid (Wrong voltage)
Possible cause:
• Wrong battery type.
• Wrong type of PCB
• Hardware failure on the power electronics.
Rectification:
1. Replace battery
2. Replace PCB (Pos. 198)
Stop
The tool is switched off.
E12
DEVICE_KEYPAD_ERROR
Description:
Keypad reports consistent pressure on keys
Possible cause:
• Keys are pressed consistent
• Keypad is defective
Rectification:
1. Release keypad
2. Replace Keypad
3. Replace PCB, (Pos. 198)
Interruption
Current process is
interrupted. Tool goes in
standby mode again.
E13
DEVICE_ORIGIN_ERROR
Description:
Error at cam switch (Pos. 103)
Possible cause:
• Defective cam switch. (always on/off)
Behebung:
1. Pull rocker lever to reset cam switch
2. Check cables and connections to cam switch
3. Replace cam switch
4. Replace PCB, (Pos 198)
Interruption
Current process is interrupted.
Tool goes in standby mode
again.
