Elektrische Installation
10 / 196
Anschlussschema EG_IO
4.2.2 EG_PoE
l PoE (802.3af, Klasse 0)
l Kabeleigenschaften: Cat. 6, STP, AWG 24/7, TIA-568A. Fast Ethernet 100Base_T unterstützt
l Verfügbare Webdienste: Web-Server, Modbus-TCP
3
Female (A)
A A
PM SiDis
PM
3
2
1
4
3
Female PM
3
7
2
1
8
4
6
5
1) 2)
Stecker-Pin-Nr. 1 2 3 4
(A) M12 4-polig Buchse D Codiert TX+ TX- RX+ RX-
