Electrical installation
26 / 196
Wiring diagram EG_IO
4.2.2 EG_PoE
l PoE (802.3af, class 0)
l Cable characteristics: Cat. 6, STP, AWG 24/7, TIA-568A. Fast Ethernet 100Base_T supported
l Available web services: Web server, Modbus TCP
3
Female (A)
A A
PM SiDis
PM
3
2
1
4
3
Female PM
3
7
2
1
8
4
6
5
1) 2)
Plug pin no. 1 2 3 4
(A) M12 4-pin socket D coded TX+ TX- RX+ RX-
